Запчасти Komatsu WA320-6 H-A ГИДР. НАСОС. ОСНОВН. НАСОС (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-02A0 )

SN: A34001--UP

-1шт.

|$1

705-41-04460

PUMP ASSEMBLY, (SB18)

SN: A34001--UP

1шт.

1

705-41-83030

BRACKET

SN: A34001--UP

1шт.

N/I

705-41-80610

BUSHING, PLANE

SN: A34001--UP

1шт.

N/I

705-41-80620

BUSHING, PLANE

SN: A34001--UP

1шт.

2

705-40-30011

CASE, GEAR

SN: A34001--UP

1шт.

3

705-40-80331

CARRIER

SN: A34001--UP

1шт.

N/I

705-41-80610

BUSHING, PLANE

SN: A34001--UP

1шт.

N/I

705-41-80620

BUSHING, PLANE

SN: A34001--UP

1шт.

4

705-40-30640

GEAR, DRIVE

SN: A34001--UP

1шт.

5

705-40-30510

GEAR, DRIVEN

SN: A34001--UP

1шт.

6

705-40-83720

PLATE, SIDE

SN: A34001--UP

2шт.

7

705-40-80770

SEAL

SN: A34001--UP

2шт.

8

04020-00820

PIN, DOWEL

SN: A34001--UP

4шт.

9

04020-01024

PIN, DOWEL

SN: A34001--UP

2шт.

10

705-67-01230

PIN, DOWEL

SN: A34001--UP

2шт.

11

01252-61280

BOLT

SN: A34001--UP

4шт.

12

01643-51232

WASHER

SN: A34001--UP

4шт.

13

705-67-01330

COUPLING ASSEMBLY

SN: A34001--UP

1шт.

14

705-17-02360

O-RING

SN: A34001--UP

1шт.

15

01252-61035

BOLT

SN: A34001--UP

4шт.

16

01643-51032

WASHER

SN: A34001--UP

4шт.

17

705-17-01880

PLATE

SN: A34001--UP

1шт.

18

07000-E3032

O-RING

SN: A34001--UP

1шт.

19

01010-81025

BOLT

SN: A34001--UP

4шт.

20

01643-51032

WASHER

SN: A34001--UP

4шт.

|$26

26

-1шт.

|$27

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

27

-1шт.
