Запчасти Komatsu WA320-6 H-A ГИДР. НАСОС. ОСНОВН. НАСОС ГИДРАВЛИКА

|$0

705-56-36051

PUMP ASSEMBLY (SAR90+32+SB18+12)

SN: A34001--UP

1шт.

|$1

705-38-39000

PUMP ASSEMBLY (SAR90)

SN: A34001--UP

1шт.

1

705-18-03620

BRACKET ASSEMBLY

SN: A34001--UP

1шт.

N/I

705-18-03350

BUSHING, PLANE

SN: A34001--UP

2шт.

2

705-17-39010

CASE, GEAR

SN: A34001--UP

1шт.

3

705-18-03240

CARRIER

SN: A34001--UP

1шт.

N/I

705-18-03350

BUSHING, PLANE

SN: A34001--UP

2шт.

4

04020-01228

PIN, DOWEL

SN: A34001--UP

4шт.

5

705-17-03381

O-RING

SN: A34001--UP

2шт.

6

705-19-39130

GEAR, DRIVE

SN: A34001--UP

1шт.

7

705-17-39810

GEAR, DRIVEN

SN: A34001--UP

1шт.

8

705-17-03610

PLATE, SIDE

SN: A34001--UP

2шт.

9

705-17-03443

RING, BACK-UP

SN: A34001--UP

2шт.

10

705-17-03473

SEAL

SN: A34001--UP

2шт.

11

01253-61635

BOLT

SN: A34001--UP

4шт.

12

01643-51645

WASHER

SN: A34001--UP

4шт.

13

705-17-03870

PLATE

SN: A34001--UP

1шт.

14

705-17-03811

SEAL, OIL

SN: A34001--UP

1шт.

15

04065-05220

RING, SNAP

SN: A34001--UP

1шт.

|$19

19

-1шт.

|$20

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

20

-1шт.
