Запчасти Komatsu WA320-6 F-A HST РЕГУЛИР. НАСОС (/) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

PUMP, VARIABLE (SEE FIG. F2430-02A0 )

SN: A34001--UP

-1шт.

1

UC47260187961

VALVE ASSEMBY

SN: A34001--UP

2шт.

|$2

UC10260012421

SEAL KIT

SN: A34001--UP

1шт.

|$3

UC10915789591

CAP

SN: A34001--UP

1шт.

2

VALVE, RELIEF (SEE FIG. F2430-07A0 )

SN: A34001--UP

-1шт.

3

VALVE, PRESSURE RELIEF (SEE FIG. F2430-08A0 )

SN: A34001--UP

-1шт.

4

UC17044906341

BUSHING, BEARING

SN: A34001--UP

1шт.

5

UC10908314511

SOCKET

SN: A34001--UP

4шт.

6

UC10983021711

O-RING

SN: A34001--UP

1шт.

7

UC10983132091

PIN

SN: A34001--UP

1шт.

8

UC17015169261

SCREW

SN: A34001--UP

1шт.

9

UC10983131991

PIN

SN: A34001--UP

3шт.

10

UC17008633311

O-RING

SN: A34001--UP

2шт.

11

UC10260185071

SCREW

SN: A34001--UP

2шт.

12

UC10943277451

BUSH

SN: A34001--UP

1шт.

13

UC17043277381

BUSHING

SN: A34001--UP

1шт.

14

UC10908349821

PIN

SN: A34001--UP

1шт.

15

INSERT (SEE FIG. F2430-08A0 )

SN: A34001--UP

-1шт.

|$18

18

-1шт.

|$19

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

19

-1шт.
