Запчасти Komatsu WA320-6 ЗАДН. МОСТ (ДИФФЕРЕНЦ. /)(№7-) СИЛОВАЯ ПЕРЕДАЧА

|$2

419-23-30010

AXLE ASS'Y,REAR

SN: 70001-UP

1шт.

|$3

419-23-30050

AXLE ASS'Y,REAR (LIMITED SLIP DIFF.)

SN: 70001-UP

1шт.

|$$3

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4500-51A0 TO F4500-57A0.

-1шт.

|$7

419-23-31010

DIFFERENTIAL ASS'Y

SN: 70001-UP

1шт.

|$8

419-23-31050

DIFFERENTIAL ASS'Y

SN: 70001-UP

1шт.

|$$6

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4500-53A0 TO F4500-55A0.

-1шт.

1

419-22-31230

COUPLING

SN: 70001-UP

1шт.

2

418-22-21310

PROTECTOR

SN: 70001-UP

1шт.

|$13

419-22-21800

PINION ASS'Y

SN: 70001-UP

1шт.

3

0

PINION

SN: 70001-UP

1шт.

4

0

PINION,BEVEL

SN: 70001-UP

1шт.

5

419-22-11810

BEARING

SN: 70001-UP

1шт.

6

419-23-21631

CAGE

SN: 70001-UP

1шт.

7

419-22-11820

BEARING

SN: 70001-UP

1шт.

8

418-22-21330

SEAL,OIL

SN: 70001-UP

1шт.

9

423-22-11240

HOLDER

SN: 70001-UP

1шт.

10

01011-61615

BOLT

SN: 70001-UP

1шт.

11

07000-13042

O-RING

SN: 70001-UP

1шт.

12

07000-15180

O-RING

SN: 70001-UP

1шт.

13

419-22-11361

SHIM, 0.05MM

SN: 70001-UP

2шт.

13

419-22-11371

SHIM, 0.2MM

SN: 70001-UP

2шт.

13

419-22-11381

SHIM, 0.3MM

SN: 70001-UP

2шт.

13

419-22-11391

SHIM, 0.8MM

SN: 70001-UP

1шт.

14

01010-61440

BOLT

SN: 70001-UP

10шт.

15

01643-31445

WASHER

SN: 70001-UP

10шт.
