Запчасти Komatsu WA320-5L K-8A ДЕМПФЕР OPERATORXD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

421-07-31260

DAMPER ASSEMBLY

SN: A32001--UP

1шт.

1

ND017321-2132

CASE, AIR DAMPER

SN: A32001--UP

1шт.

2

ND116471-7180

BRACKET, CASE

SN: A32001--UP

2шт.

3

ND90930-06161

SCREW

SN: A32001--UP

12шт.

4

ND116471-7190

BRACKET, CASE

SN: A32001--UP

2шт.

5

ND017321-3071

CASE, AIR DAMPER

SN: A32001--UP

1шт.

6

ND90900-04161

SCREW, TAPPING

SN: A32001--UP

5шт.

7

ND116730-0710

DOOR

SN: A32001--UP

1шт.

8

ND017732-4880

LEVER, CONTROL

SN: A32001--UP

1шт.

9

ND91370-03081

SCREW WITH WASHER

SN: A32001--UP

1шт.

10

ND063700-5731

SERVO MOTOR ASSEMBLY

SN: A32001--UP

1шт.

11

ND017773-0190

CLIP

SN: A32001--UP

1шт.

12

ND90940-05101

SCREW, TAPPING

SN: A32001--UP

11шт.

13

ND145531-1200

HOLDER

SN: A32001--UP

1шт.

14

20Y-979-6261

FILTER ASSEMBLY

SN: A32001--UP

2шт.

15

ND145531-1200

HOLDER

SN: A32001--UP

1шт.

16

ND146648-1171

PACKING

SN: A32001--UP

1шт.

17

ND146637-0480

PACKING

SN: A32001--UP

2шт.

18

ND040033-4720

CLAMP

SN: A32001--UP

1шт.

19

ND146648-6791

PACKING

SN: A32001--UP

1шт.

20

ND246634-8580

BRACKET

SN: A32001--UP

1шт.

21

ND246451-0200

WIRE, AIR CONDITIONER

SN: A32001--UP

1шт.

22

ND146522-6190

BRACKET

SN: A32001--UP

1шт.

23

ND146984-4030

GROMMET

SN: A32001--UP

1шт.

24

ND90940-05161

SCREW, TAPPING

SN: A32001--UP

6шт.

25

195-Z11-6280

BUSHING

SN: A32001--UP

1шт.
