Запчасти Komatsu WA320-5L A-AA ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ

|$0

6737-32-3121

ENGINE ROD ASSEMBLY

6шт.

1

NSS

ROD, ENGINE CONNECTING

1шт.

2

6732-31-3320

BOLT, CONNECTING ROD CAP

2шт.

3

6732-31-3132

BUSHING

1шт.

4

6732-31-3420

BEARING, CONNECTING ROD LOWER (STD)

6шт.

5

6754-32-3410

BEARING, CONNECTING ROD UPPER (STD)

6шт.

6

6738-32-2010

KIT, ENGINE PISTON (STD)

1шт.

|$7

6738-31-2111

PISTON, ENGINE

1шт.

7

6732-31-2420

RING, RETAINING

12шт.

8

6738-31-2030

SET, PISTON RING

1шт.

9

6731-31-2410

PIN, PISTON

6шт.

|$28

SERVICE PARTS

11

-1шт.

4

6738-39-3400

BEARING, CONNECTING ROD (0.25 MM OS)

-2шт.

4

6738-38-3400

BEARING, CONNECTING ROD (0.50 MM OS)

-2шт.

4

6738-37-3400

BEARING, CONNECTING ROD (0.75 MM OS)

-2шт.

4

6738-36-3400

BEARING, CONNECTING ROD (1.00 MM OS)

-2шт.

5

6736-39-3400

BEARING, CONNECTING ROD (0.25 MM OS)

-2шт.

5

6736-38-3400

BEARING, CONNECTING ROD (0.50 MM OS)

-2шт.

5

6736-37-3400

BEARING, CONNECTING ROD (0.75 MM OS)

-2шт.

5

6736-36-3400

BEARING, CONNECTING ROD (1.00 MM OS)

-2шт.

|$20

6738-32-2020

KIT, ENGINE PISTON (0.50 MM OS)

-2шт.

6

NSS

PISTON, ENGINE

1шт.

7

6732-31-2420

RING, RETAINING

2шт.

8

6738-39-2030

SET, PISTON RING

1шт.

|$24

6738-32-2030

KIT, ENGINE PISTON (1.00 MM OS)

-2шт.

6

NSS

PISTON, ENGINE

1шт.

7

6732-31-2420

RING, RETAINING

2шт.

8

6738-38-2030

SET, PISTON RING

1шт.
