Запчасти Komatsu WA320-5L A-AA7 БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6731-21-1270

BLOCK, CYLINDER

1шт.

1

NSS

BLOCK, CYLINDER

1шт.

2

6732-21-1411

BUSHING

1шт.

3

6732-21-1611

BOLT, HEX FLANGE HEAD CAP

14шт.

|$4

6754-21-1220

CAP, MAIN BEARING

7шт.

4

6754-21-1210

CAP, MAIN BEARING

1шт.

5

6732-21-1910

DOWEL, RING

2шт.

6

6732-21-1820

PLUG, EXPANSION

4шт.

7

6732-21-1810

PLUG, EXPANSION

3шт.

8

6731-22-7140

PLUG, EXPANSION

5шт.

|$10

6736-01-2110

KIT, CYLINDER BLOCK

1шт.

N/I

6732-21-1411

BUSHING

1шт.

N/I

6732-21-1910

DOWEL, RING

2шт.

9

6732-21-6140

DOWEL, RING

2шт.

10

6731-21-1190

NOZZLE, PISTON COOLING

6шт.

11

6732-21-6130

PLUG, EXPANSION

1шт.

12

6732-21-6120

DOWEL, PIN

1шт.

13

6732-11-1910

PLUG, PIPE

1шт.

|$18

6732-21-1960

PLUG, THREADED

3шт.

14

6215-81-9510

PLUG, THREADED

1шт.

15

6215-81-9710

SEAL, O-RING

1шт.

16

6735-21-5530

PLUG, EXPANSION

2шт.

17

6732-21-5530

PLUG, EXPANSION

3шт.

18

6732-21-6160

PLUG, EXPANSION

1шт.

|$24

6732-21-1910

PLUG, THREADED

1шт.

19

6735-21-1930

SEAL, O-RING

1шт.

20

6735-21-1910

PLUG, THREADED

1шт.

21

6732-21-1930

SEAL, O-RING

1шт.

22

6732-11-1920

PLUG, PIPE

1шт.

23

6732-21-3120

SCREW, HEX FLANGE HEAD CAP

1шт.

|$30

6735-21-1940

PLUG, O-RING

1шт.

24

6745-11-1910

SEAL, O-RING

1шт.

25

6735-21-1940

PLUG, O-RING

1шт.

26

6745-11-1910

PLUG, PIPE

1шт.

27

6745-21-4110

PLUG, PIPE

1шт.

|$40

SERVICE PARTS

35

-1шт.

|$36

6736-29-1410

BUSHING, OVERSIZE (NO. 1 BORE)

-2шт.

|$37

6736-29-1420

BUSHING, OVERSIZE (NO. 2-5 BORE)

-2шт.

|$38

6731-21-1260

CAP, BEARING MAIN

7шт.

28

6736-29-2110

SLEEVE, SALVAGE

-2шт.
