Запчасти Komatsu WA320-5 CENTRAL СМАЗКА СИСТЕМА (ФИДЕР ЗАДН. РАМА) J РАМА И ITS КОМПОНЕНТЫ

|$1

0

FEEDER REAR FRAME

SN: H50051-UP

1шт.

1

419-09-H2730

FEEDER

SN: H50051-UP

1шт.

2

42W-09-H4640

VALVE

SN: H50051-UP

5шт.

3

01252-70640

SCREW

SN: H50051-UP

2шт.

4

419-09-H2860

SCREW LOCKING DEVICE

SN: H50051-UP

2шт.

5

01642-20610

WASHER

SN: H50051-UP

2шт.

6

419-09-H2770

UNION

SN: H50051-UP

1шт.

7

421-09-H3870

LUBRICATION NIPPLE

SN: H50051-UP

1шт.

8

42W-09-H3350

CAP

SN: H50051-UP

1шт.

9

419-09-H2780

UNION

SN: H50051-UP

1шт.

10

42W-09-H2940

SAFETY CAP

SN: H50051-UP

6шт.

11

42W-09-H0P06

HOSE, 5M

SN: H50051-UP

-26шт.

11

42W-09-H0P07

HOSE, 10M

SN: H50051-UP

-26шт.

11

42W-09-H0P08

HOSE, 25M

SN: H50051-UP

-26шт.

12

42W-09-H0P11

HOSE PROTECTOR, 10M, 10MM

SN: H50051-UP

-26шт.

12

42W-09-H0P12

HOSE PROTECTOR, 10M, 16MM

SN: H50051-UP

-26шт.

13

423-00-H1920

BUSHING

SN: H50051-UP

6шт.

14

42T-09-H3810

TUBE

SN: H50051-UP

6шт.

15

42W-09-H0P00

HOSE, 5M

SN: H50051-UP

-26шт.

15

42W-09-H0P01

HOSE, 10M

SN: H50051-UP

-26шт.

15

42W-09-H0P02

HOSE, 25M

SN: H50051-UP

-26шт.
