Запчасти Komatsu WA320-5 CENTRAL СМАЗКА СИСТЕМА (ФИДЕР ПЕРЕДН. РАМА) (/) J РАМА И ITS КОМПОНЕНТЫ

|$1

0

FEEDER FRONT FRAME (STD BOOM)

SN: H50051-UP

1шт.

|$2

0

FEEDER FRONT FRAME (HIGH LIFT BOOM)

SN: H50051-UP

1шт.

1

419-09-H2670

FEEDER

SN: H50051-UP

1шт.

2

42W-09-H4640

VALVE

SN: H50051-UP

11шт.

3

419-09-H2770

UNION

SN: H50051-UP

1шт.

4

425-09-H0240

ELBOW

SN: H50051-UP

1шт.

5

421-09-H3870

LUBRICATION NIPPLE

SN: H50051-UP

1шт.

6

42W-09-H3350

CAP

SN: H50051-UP

1шт.

7

419-09-H2780

UNION

SN: H50051-UP

1шт.

8

42W-09-H2940

SAFETY CAP

SN: H50051-UP

12шт.

9

42W-09-H0P00

HOSE, 5M

SN: H50051-UP

-26шт.

9

42W-09-H0P01

HOSE, 10M

SN: H50051-UP

-26шт.

9

42W-09-H0P02

HOSE, 25M

SN: H50051-UP

-26шт.

10

423-00-H1920

BUSHING

SN: H50051-UP

1шт.

11

42T-09-H3810

TUBE

SN: H50051-UP

1шт.

12

42W-09-H0P06

HOSE, 5M

SN: H50051-UP

-26шт.

12

42W-09-H0P07

HOSE, 10M

SN: H50051-UP

-26шт.

12

42W-09-H0P08

HOSE, 25M

SN: H50051-UP

-26шт.

13

42W-09-H0P11

HOSE PROTECTOR, 10M, 10MM

SN: H50051-UP

-26шт.

13

42W-09-H0P12

HOSE PROTECTOR, 10M, 16MM

SN: H50051-UP

-26шт.
