Запчасти Komatsu WA320-5 СТАРТЕР (.KM) (ВНУТР. ЧАСТИ) КОМПОНЕНТЫ ДВИГАТЕЛЯ

|1

600-863-5111

STARTING MOTOR ASS'Y (5.5KW)

SN: B10001-UP

1шт.

1

ND028100-5410

YOKE ASS'Y

SN: B10001-UP

1шт.

2

ND028200-5250

ARMATURE ASS'Y

SN: B10001-UP

1шт.

3

ND949100-3161

BEARING {BALL}

SN: B10001-UP

1шт.

|3

ND949100-5290

BEARING {BALL}

SN: B10001-UP

1шт.

4

ND949100-3540

BEARING {BALL}

SN: B10001-UP

1шт.

|4

ND028300-6551

CLUTCH ASS'Y

SN: B10001-UP

1шт.

5

ND028099-3270

STARTER KIT

SN: B10001-UP

1шт.

6

ND028300-6751

CLUTCH ASS'Y

SN: B10001-UP

1шт.

7

ND949100-4501

BEARING {BALL¤ FRONT}

SN: B10001-UP

1шт.

8

ND949100-1920

BEARING {BALL¤ REAR}

SN: B10001-UP

1шт.

9

ND949170-4040

SPRING

SN: B10001-UP

1шт.

10

ND028381-0071

SHAFT

SN: B10001-UP

1шт.

11

ND128401-5621

HOUSING

SN: B10001-UP

1шт.

12

ND153400-6740

SWITCH ASS'Y {MAGNETIC}

SN: B10001-UP

1шт.

13

ND128099-5770

KIT {STARTER}

SN: B10001-UP

1шт.

14

ND028099-5100

KIT {STARTER}

SN: B10001-UP

1шт.

15

ND053660-0443

PLUNGER

SN: B10001-UP

1шт.

16

ND053404-0240

GASKET

SN: B10001-UP

1шт.

17

ND053505-0290

COVER {SOLENOID}

SN: B10001-UP

1шт.

18

ND053480-7560

BOLT ASS'Y {TERMINAL}

SN: B10001-UP

1шт.

19

ND949047-4440

BOLT

SN: B10001-UP

3шт.

20

ND028065-0250

BUSHING {DRAIN}

SN: B10001-UP

1шт.

21

ND028510-0880

HOLDER ASS'Y {BRUSH}

SN: B10001-UP

1шт.

22

ND028520-0011

SPRING {BRUSH}

SN: B10001-UP

4шт.

23

ND028501-7711

FRAME

SN: B10001-UP

1шт.

24

ND128961-0010

BALL {STEEL}

SN: B10001-UP

1шт.

25

ND949170-4070

SPRING

SN: B10001-UP

1шт.

26

ND028371-3210

PINION {STARTER}

SN: B10001-UP

1шт.

27

ND028306-0070

ROLLER {CLUTCH}

SN: B10001-UP

5шт.

28

ND028063-0030

RETAINER

SN: B10001-UP

1шт.

29

ND028062-0130

CAP

SN: B10001-UP

1шт.

30

ND949042-3680

BOLT

SN: B10001-UP

1шт.

31

ND90801-10050

O-RING

SN: B10001-UP

3шт.

32

ND949042-3690

BOLT

SN: B10001-UP

1шт.

33

ND949006-4720

SCREW

SN: B10001-UP

3шт.

34

ND949056-4480

NUT

SN: B10001-UP

1шт.

35

ND028327-0171

RETAINER {SNAP}

SN: B10001-UP

1шт.

36

ND90258-10001

WASHER {SPRING}

SN: B10001-UP

1шт.

37

ND028901-0361

SEAL

SN: B10001-UP

2шт.

38

ND028371-3200

PINION

SN: B10001-UP

1шт.

39

ND949007-6530

SCREW

SN: B10001-UP

4шт.

40

ND028530-1090

BRUSH ASS'Y

SN: B10001-UP

2шт.

41

ND028530-1100

BRUSH ASS'Y

SN: B10001-UP

2шт.

42

ND949007-6850

SCREW

SN: B10001-UP

1шт.

43

ND028062-5790

COVER

SN: B10001-UP

1шт.

44

ND90170-10061

NUT

SN: B10001-UP

1шт.

45

ND028901-5190

SEAL

SN: B10001-UP

1шт.

46

ND90200-06241

WASHER

SN: B10001-UP

3шт.
