Запчасти Komatsu WA320-3MC FIG NO. B-A ДВИГАТЕЛЬ И АКСЕССУАРЫ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

419-01-A2000

ENGINE ASSEMBLY (SEE SECTION A)

-29шт.

2

STARTER MOTOR ASSEMBLY (SEE PG B-036)

-29шт.

|$2

01010-81245

BOLT, MOUNTING STARTER MOTOR

3шт.

|$3

01643-31232

WASHER

3шт.

|$4

1211 455 H2

GASKET, STARTER MOTOR

1шт.

3

1286 822 H91

ALTERNATOR (SEE PG B-036)

-29шт.

4

206-01-A1140

SENSOR ASSEMBLY, ENGINE OIL LEVEL

1шт.

|$7

206-01-A1160

SENSOR, ENGINE OIL LEVEL

1шт.

|$8

1209 470 H1

CONNECTOR, MALE

1шт.

|$9

1209 477 H1

SEAL, TERMINAL

4шт.

|$10

1209 466 H1

TERMINAL

4шт.

5

206-01-A1150

SWITCH, ENGINE OIL PRESSURE

1шт.

6

206-01-A1130

SENSOR, ENGINE COOLANT TEMPERATURE

1шт.

|$13

24 466 R1

BUSHING, REDUCER (3/4x1/2 INCH)

1шт.

7

MUFFLER, EXHAUST (SEE PG B-026)

-29шт.

8

AIR CLEANER ASSEMBLY (SEE PG B-018)

-29шт.

9

FAN, BLOWER - ENGINE (SEE PG B-028)

-29шт.

10

SPACER, FAN (SEE PG B-028)

-29шт.

|$18

01011-81015

BOLT, FAN MOUNTING

4шт.

|$19

01643-31032

WASHER

4шт.

11

419-01-A1360

SHIELD, ALTERNATOR

1шт.

|$23

-1шт.

|$22

F1 - SERVICE PARTS IN SECTION A

-1шт.

|$24

-1шт.
