Запчасти Komatsu WA320-3MC FIG NO. U-A МАРКИРОВКА МАРКИРОВКА

|$0

421-93-21311

PLATE, KIT

1шт.

1

NSS

PLATE, SAFETY, RADIATOR CAP

1шт.

2

NSS

PLATE, SAFETY, BATTERY CABLE

2шт.

3

NSS

PLATE, INSTRUCTION, ENGINE OIL DRAIN

1шт.

4

NSS

PLATE, SAFETY, SAFETY BAR

1шт.

5

NSS

PLATE, SAFETY, KEEP OUT

2шт.

6

NSS

PLATE, INSTRUCTION, FUEL

1шт.

7

NSS

PLATE, INSTRUCTION, RADIATOR DRAIN

1шт.

8

NSS

PLATE, SAFETY, HYDRAULIC TANK CAP

1шт.

9

419-93-A2110

CHART, OIL

1шт.

10

417-93-21220

PLATE, MARK, AVANCE LOADER

2шт.

11

419-93-A1330

PLATE, MARK, WA320

2шт.

12

417-93-21150

PLATE, STRIPE, L.H

1шт.

13

417-93-21160

PLATE, STRIPE, R.H

1шт.

14

417-93-21141

PLATE, MARK, KOMATSU

1шт.

15

419-93-21240

PLATE, INSTRUCTION, REAR AXLE PIVOT PIN

1шт.

16

09812-13000

PLATE, CAUTION, KEEP A SAFE DISTANCE

2шт.

17

09667-03001

PLATE, SAFETY, FAN

2шт.

18

09812-13000

PLATE, CAUTION, KEEP A SAFE DISTANCE

2шт.

19

09960-01001

PLATE, MARK, HANDLING

4шт.

20

09690-C0560

PLATE, MARK, KOMATSU

2шт.

21

419-93-A2130

PLATE, SAFETY, JUMP START

2шт.

22

419-93-A2120

PLATE, GREASE

1шт.

23

09690-D0355

PLATE, KOMATSU

2шт.

24

09690-D0800

DECAL, KOMATSU, BOOM

2шт.

25

09659-53000

DECAL, WARNING, ACCUMULATOR

3шт.

26

419-93-A2340

DECAL, PLUS, HOOD

2шт.

27

419-93-A2160

DECAL, CAUTION, RADIATOR

1шт.

28

419-93-A1180

PLATE, PRODUCT IDENTIFICATION

1шт.
