Запчасти Komatsu WA320-3MC ПОРШЕНЬ И ШАТУН ДВИГАТЕЛЬ - SADE-

|$0

1240 906 H91

ROD, ENGINE CONNECTING

6шт.

1

NSS

ROD, CONNECTING

1шт.

2

1304 869 H1

BOLT, CONNECTING ROD

2шт.

3

6742-01-4340

NUT, HEX (M12-1.25)

2шт.

4

6742-01-2740

BUSHING

1шт.

5

6742-01-2750

BEARING, ROD HALF - STD

12шт.

|$6

6742-01-2810

BEARING, ROD HALF - 0.25mm OVERSIZE

12шт.

|$7

6742-01-2820

BEARING, ROD HALF - 0.50mm OVERSIZE

12шт.

|$8

6742-01-2830

BEARING, ROD HALF - 0.75mm OVERSIZE

12шт.

|$9

6742-01-2840

BEARING, ROD HALF - 1.00mm OVERSIZE

12шт.

|$10

1304 902 H91

KIT, ENGINE PISTON

6шт.

6

NSS

PISTON, ENGINE

1шт.

7

6742-01-2780

RING, RETAINING

2шт.

8

1241 748 H92

SET, PISTON RING

1шт.

9

6742-01-2800

PIN, PISTON

6шт.

|$$16

-1шт.

|$16

CYLINDER KIT

-1шт.

|$17

1307 230 H91

KIT, CYLINDER

6шт.

|$18

6742-01-1500

KIT, LINER

1шт.

|$19

1304 902 H91

KIT, ENGINE PISTON

1шт.
