Запчасти Komatsu WA320-3L FIG. E-A АККУМУЛЯТОР КАБЕЛЬS ЭЛЕКТРИКА

1

08088-30000

RELAY, BATTERY

SN: A30001--UP

1шт.

2

01220-40408

SCREW

SN: A30001--UP

2шт.

3

01601-20410

WASHER

SN: A30001--UP

2шт.

4

01220-40420

SCREW

SN: A30001--UP

2шт.

5

01601-20410

WASHER

SN: A30001--UP

2шт.

6

419-06-21110

BRACKET

SN: A30001--UP

1шт.

7

01435-00825

BOLT

SN: A30001--UP

2шт.

8

01435-00816

BOLT

SN: A30001--UP

2шт.

9

421-06-22880

HOLDER, FUSE

SN: A30001--UP

2шт.

|$9

421-06-22990

BOLT

SN: A30001--UP

8шт.

10

421-06-22820

FUSE, 80A - SLOW BLOW

SN: A30001--UP

1шт.

11

421-06-22840

FUSE, 30A

SN: A30001--UP

1шт.

12

421-06-22910

BRACKET

SN: A30001--UP

2шт.

13

421-06-22920

BRACKET

SN: A30001--UP

2шт.

14

01435-00816

BOLT

SN: A30001--UP

2шт.

15

424-06-12520

CABLE, BATTERY TO BATTERY

SN: A30001--UP

1шт.

16

08028-45070

CABLE, BATTERY GROUND

SN: A30001--UP

1шт.

17

08028-45175

CABLE, RELAY TO BATTERY

SN: A30001--UP

1шт.

18

424-09-12530

BOOT

SN: A30001--UP

2шт.

19

424-09-12540

BOOT

SN: A30001--UP

2шт.

20

01010-81016

BOLT

SN: A30001--UP

1шт.

21

01643-31032

WASHER

SN: A30001--UP

1шт.

22

419-06-22240

CABLE, BATTERY RELAY TO STARTING MOTOR

SN: A30001--UP

1шт.

23

421-06-22410

CABLE, RELAY TO FUSES

SN: A30001--UP

1шт.

24

423-06-22550

CABLE, RELAY TO FUSES

SN: A30001-A30405-UP

1шт.

|$25

-1шт.

|$26

OR

-1шт.

|$27

-1шт.

|$28

423-06-A1170

CABLE, RELAY TO FUSES

SN: A30406--UP

1шт.

25

08038-00035

CAP

SN: A30001--UP

3шт.

26

419-06-22250

CABLE, STARTING MOTOR GROUND

SN: A30001--UP

1шт.

27

01010-51225

BOLT

SN: A30001--UP

1шт.

28

01643-31232

WASHER

SN: A30001--UP

2шт.

29

08036-01814

CLIP

SN: A30001--UP

5шт.
