Запчасти Komatsu WA320-3L FIG. B-A ДВИГАТЕЛЬ И АКСЕССУАРЫ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

419-01-A2000

ENGINE ASSEMBLY

SN: A30001--UP

1шт.

2

MOTOR ASSEMBLY, STARTER (SEE FIG. A6112-A3A4)

SN: A30001--UP

1шт.

|$2

01010-51250

BOLT, MOUNTING CRANKING MOTOR

SN: A30001-A30468-UP

3шт.

|$3

01010-81245

BOLT, MOUNTING CRANKING MOTOR

SN: A30469--UP

3шт.

|$4

01643-31232

WASHER

SN: A30001--UP

3шт.

|$5

1211 455 H2

GASKET, CRANKING MOTOR

SN: A30001--UP

1шт.

|$6

446 839 C2

GASKET, LIQUID - CRANKING MOTOR

SN: A30001--UP

1шт.

3

ALTERNATOR (SEE FIG. B6010-B2D2A)

SN: A30001--UP

1шт.

4

206-01-A1140

SENSOR ASSEMBLY, ENGINE OIL LEVEL

SN: A30001--UP

1шт.

|$9

206-01-A1160

SENSOR, ENGINE OIL LEVEL

SN: A30001--UP

1шт.

|$10

1209 470 H1

CONNECTOR, MALE

SN: A30001--UP

1шт.

|$11

1209 477 H1

SEAL, TERMINAL

SN: A30001--UP

4шт.

|$12

1209 466 H1

TERMINAL

SN: A30001--UP

4шт.

5

1312 855 H1

SWITCH, ENGINE OIL PRESSURE

SN: A30001--UP

1шт.

6

206-01-A1130

SENSOR, ENGINE COOLANT TEMPERATURE

SN: A30001--UP

1шт.

7

MUFFLER, EXHAUST (SEE FIG. B1610-A2A6)

SN: A30001--UP

1шт.

8

CLEANER ASSEMBLY, AIR (SEE FIG. B1410-A2A8A)

SN: A30001--UP

1шт.

9

1237 733 H1

FAN, BLOWER - ENGINE

SN: A30001--UP

1шт.

10

1237 716 H1

SPACER, FAN PILOT

SN: A30001--UP

1шт.

|$19

01011-51010

BOLT, FAN MOUNTING

SN: A30001--UP

4шт.

|$20

01643-31032

WASHER

SN: A30001--UP

4шт.

11

419-01-A1360

SHIELD, ALTERNATOR

SN: A30001--UP

1шт.

|$22

01435-01225

BOLT

SN: A30001--UP

2шт.

12

419-06-21320

BRACKET, RELAY MOUNTING

SN: A30001--UP

1шт.

13

419-06-21310

RELAY, STARTER DISABLE

SN: A30001--UP

1шт.

|$25

01435-00618

BOLT

SN: A30001--UP

2шт.

|$26

-1шт.

|$27

F1 FOR SERVICE PARTS, SEE SECTION A

-1шт.

|$28

-1шт.

|$29

-1шт.

|$30

F2 S/N A30001 - A30468

-1шт.

|$31

-1шт.

|$32

-1шт.

|$33

F3 S/N A30469 AND UP

-1шт.

|$34

-1шт.
