Запчасти Komatsu WA320-3L FIG. A-AA СТАРТЕР - MT - ТИП - V ДВИГАТЕЛЬ

Схема запчастей Komatsu WA320-3L - FIG. A-AA СТАРТЕР - MT - ТИП - V ДВИГАТЕЛЬ
6
5
9
8
4
7
3
2
1
19
23
33
32
28
20
31
22
30
21
10
11
29
12
18
27
26
25
24
14
48
47
46
13
17
40
16
41
42
15
43
39
49
38
54
53
36
45
52
35
44
51
34
37
1
50

Артикул

Название

Примечание

Количество

|$0

6743-82-6130

MOTOR, STARTER PRODUCTION

1шт.

|$1

1243 215 H92

MOTOR, STARTER SERVICE

1шт.

1

1277 066 H1

LEAD, C.E. TERMINAL TO SOLENOID SWITCH

1шт.

|$3

NSS

NUT, SHUNT LEAD TO SWITCH

1шт.

2

1316 560 H1

SWITCH, SOLENOID

1шт.

|$5

1283 448 H1

SCREW AND WASHER, SWITCH MOUNTING

1шт.

3

1228 450 H1

PLUNGER, SOLENOID

1шт.

4

1210 070 H1

WASHER, RETAINER

1шт.

5

1210 071 H1

BOOT, PLUNGER

1шт.

6

1210 072 H1

RETAINER, PLUNGER SPRING

1шт.

7

1210 073 H1

SPRING, PLUNGER

1шт.

8

1210 074 H1

RETAINER, PLUNGER SPRING

1шт.

|$12

1223 258 H91

HOUSING ASSEMBLY, LEVER

1шт.

9

213 262 R1

RING, RETAINER

1шт.

10

355 967 R1

O-RING

1шт.

11

1211 152 H1

SHAFT, SHIFT LEVER

1шт.

12

352 219 R1

O-RING

1шт.

13

1211 285 H1

SEAL, OIL

1шт.

14

NSS

HOUSING, LEVER

1шт.

|$19

1245 107 H1

SCREW, LEVER HOUSING

1шт.

15

NSS

HOUSING

1шт.

16

NSS

WASHER, SPACER - D.E.

1шт.

17

NSS

O-RING

1шт.

18

NSS

O-RING

1шт.

19

NSS

CUP, OIL RESERVOIR - LEVER HOUSING

1шт.

20

NSS

WICK, OIL RESERVOIR - LEVER HOUSING

1шт.

21

NSS

GASKET, INSPECTION PLUG

1шт.

22

1210 066 H1

PLUG, INSPECTION

1шт.

23

NSS

NUT, PLUNGER ROD GUIDE ADJUSTING

1шт.

24

NSS

RING, SNAP - SHIFT LEVER SHAFT

1шт.

25

NSS

BUSHING, LEVER HOUSING

1шт.

26

NSS

WASHER, BRAKE

1шт.

27

NSS

LEVER, SHIFT

1шт.

28

1228 604 H1

DRIVE ASSEMBLY

1шт.

|$34

1223 260 H91

HOUSING ASSEMBLY, D.E.

1шт.

29

347 360 R1

O-RING

1шт.

30

NSS

HOUSING, D.E.

1шт.

|$37

1245 105 H1

SCREW, DRIVE HOUSING

1шт.

31

1211 288 H1

BUSHING, DRIVE HOUSING

1шт.

32

NSS

WICK, OIL RESERVOIR - D.E.

1шт.

33

NSS

CUP, OIL RESERVOIR - D.E.

1шт.

34

NSS

O-RING

1шт.

35

1223 265 H1

TERMINAL AND LEAD ASSEMBLY

1шт.

36

NSS

SPRING, BRUSH

1шт.

37

NSS

BRUSH

1шт.

|$45

NSS

SCREW - BRUSH AND FIELD COIL LEAD TO BRUSH

-1шт.

38

1284 360 H91

PLATE ASSEMBLY, BRUSH

1шт.

39

NSS

WASHER, THRUST

1шт.

40

1228 452 H1

CONNECTOR

1шт.

|$49

1211 267 H1

NUT, FIELD COIL CONNECTOR TO SWITCH

1шт.

|$50

1283 448 H1

SCREW AND WASHER, CONNECTOR TO FIELD ATTACH

1шт.

41

1210 062 H1

INSULATOR, FIELD TERMINAL

1шт.

42

1210 061 H1

INSULATOR, FIELD TERMINAL

1шт.

43

1228 453 H1

INSULATOR, FIELD COIL

1шт.

44

1223 256 H1

ARMATURE

1шт.

45

1228 454 H1

PIN, SPRING

1шт.

46

1211 263 H1

SHOE, POLE

1шт.

47

1245 108 H1

SCREW, POLE SHOE

1шт.

48

1211 271 H1

INSULATOR, FIELD COIL

1шт.

49

1228 605 H1

COIL ASSEMBLY

1шт.

50

1223 269 H91

PACKAGE, SERVICE INSULATION - C.E. TERMINAL

1шт.

51

NSS

CUP, OIL RESERVOIR - C.E.

1шт.

52

NSS

WICK, OIL RESERVOIR - C.E.

1шт.

53

1223 255 H1

HOUSING, C.E.

1шт.

|$64

120 238

NUT, TERMINAL - C.E.

1шт.

|$65

1211 267 H1

NUT AND WASHER, C.E. FRAME

1шт.

|$66

120 239

WASHER, LOCK - TERMINAL STUD C.E.

1шт.

|$67

120 396

WASHER, TERMINAL - C.E. FRAME

1шт.

54

NSS

BUSHING, COVER

1шт.

|$69

1305 530 H1

SHIELD, TERMINAL

1шт.

|$70

1305 531 H1

NUT, HEX

1шт.

|$71

1223 266 H91

KIT, SERVICE - BUSHINGS

1шт.

|$72

1223 267 H91

KIT, SERVICE - SHIFT LEVER

1шт.

|$73

1223 268 H91

KIT, SERVICE - 24V BRUSH

1шт.

|$77

-1шт.

|$78

F1 INCLUDED IN SERVICE PACKAGE 1223 267 H91

-1шт.

|$80

-1шт.

|$81

F2 INCLUDED IN SERVICE PACKAGE 1223 266 H91INCLUDED IN SERVICE PACKAGE 1223 268 H91

-1шт.

|$83

-1шт.

|$82

F3 INCLUDED IN SERVICE PACKAGE 1223 268 H91

-1шт.

|$84

-1шт.

|$75

R1 PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER THE SERVICE STARTER.

-1шт.
