Запчасти Komatsu WA320-3L FIG. A-AA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6742-01-5530

HEAD, CYLINDER

1шт.

1

NSS

HEAD, CYLINDER

1шт.

2

1296 803 H1

PLUG, EXPANSION

1шт.

3

6742-01-2920

PLUG, EXPANSION

5шт.

4

6736-21-1810

PLUG, EXPANSION

2шт.

5

6742-01-3240

GUIDE, VALVE STEM

12шт.

6

1307 586 H1

INSERT, VALVE - EXHAUST

6шт.

7

1241 223 H2

INSERT, VALVE - INTAKE

6шт.

8

6742-01-2960

PLUG, PIPE (1/16 NPT)

1шт.

9

6732-61-2240

PLUG, PIPE (1/4 NPT)

1шт.

10

6732-11-1910

PLUG, PIPE (1/2 NPT)

1шт.

11

6742-01-5224

SEAL, VALVE STEM - INTAKE

6шт.

|$12

1296 823 H1

VALVE, ASSEMBLY, EXHAUST

6шт.

12

NSS

VALVE, INTAKE

1шт.

13

6742-01-2990

COLLET, VALVE

12шт.

|$15

6742-01-3000

VALVE, ASSEMBLY, EXHAUST

6шт.

14

NSS

VALVE, EXHAUST

6шт.

15

6742-01-2990

COLLET, VALVE

12шт.

16

6732-21-5170

WASHER, SEALING

2шт.

17

6736-21-5320

PLUG, THREADED (M22-1.50)

2шт.

18

6741-41-4410

SPRING, VALVE

12шт.

19

6742-01-3030

RETAINER, VALVE SPRING

12шт.

20

6742-01-5224

SEAL, VALVE STEM - EXHAUST

6шт.

21

6742-01-3250

PLUG, EXPANSION

1шт.

22

1294 847 H2

COUPLING, ELBOW HOSE

1шт.

23

6742-01-4360

GASKET, CYLINDER HEAD

1шт.

24

6742-01-3270

BOLT (M14-2.00x80)

12шт.

25

6743-11-1610

BOLT (M14-2.00x160)

14шт.

|$28

-1шт.

|$29

SERVICE PARTS

-1шт.

|$30

-1шт.

|$31

6742-01-5172

GASKET, CYLINDER HEAD 0.25MM OVERSIZE

1шт.

|$32

6742-01-5174

GASKET, CYLINDER HEAD 0.50MM OVERSIZE

1шт.

|$33

-1шт.

|$34

F1 REPLACES ITEM 21 P/N 6742-01-3250 WHEN AIR COMPRESSOR IS USED.

-1шт.

|$35

-1шт.
