Запчасти Komatsu WA320-3 ПРИВОДRS СИДЕНЬЕ, ATTACHING ЧАСТИ ПРИВОДRS КАБИНА

1

423-960-H010

SEAT

EnglischBem: ORDER 423-960-H011

1шт.

1A

423-960-H011

SEAT

DeutschDesc: SITZ

1шт.

2

423-57-H0P02

BACK REST

EnglischBem: NOTE: Pos. (2) included in Pos. (1) and (1A) Kit

1шт.

2A

423-57-H0P44

BACKREST COVERING

DeutschDesc: LEHNENBEZUG

1шт.

3

423-57-H0P03

HEAD REST

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (1A) Kit

1шт.

4

423-57-H0P04

CLAMP

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (1A) Kit

2шт.

5

423-57-H0P05

SEAT CUSHION

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (1A) Kit

1шт.

5A

423-57-H0P45

SEAT COVERING

DeutschDesc: SITZBEZUG

1шт.

6

423-57-H0P06

ARM REST

DeutschDesc: ARMLEHNE

1шт.

6A

423-57-H0P49

ARM REST

EnglischBem: LEFT

1шт.

7

423-57-H0P07

ARM REST

DeutschDesc: ARMLEHNE

1шт.

7A

423-57-H0P50

ARM REST

EnglischBem: RIGHT

1шт.

8

423-57-H0P08

COVERING

EnglischBem: NOTE: Pos. (8) included in Pos. (6) and (7) Kit

2шт.

9

423-57-H0P09

SCREW

EnglischBem: NOTE: Pos. (9) included in Pos. (6) and (7) Kit

4шт.

10

423-57-H0P10

BUTTON

EnglischBem: NOTE: Pos. (10) included in Pos. (6) and (7) Kit

2шт.

11

01010-50825

SCREW

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (1A) Kit

4шт.

12

01602-20825

SPRING WASHER

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (1A) Kit

4шт.

13

423-57-H0P11

CAP

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (1A) Kit

4шт.

14

423-57-H0P12

FRAME

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (1A) Kit

1шт.

14A

42Y-57-H0P02

BOTTOM PART

EnglischBem: NOTE: Pos. (14A) included in Pos. (1) and (1A) Kit

1шт.

14B

421-57-H0P55

BELLOWS

EnglischBem: NOTE: Pos. (14B) included in Pos. (1) and (1A) Kit

1шт.

15

423-57-H0P13

GRIP

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (1A) Kit

1шт.

16

423-57-H0P14

GRIP

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (1A) Kit

1шт.

17

423-57-H0P15

GRIP

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (1A) Kit

1шт.

18

423-57-H0P16

SHOCK ABSORBER

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (1A) Kit

1шт.

19

01010-30840

SCREW

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (1A) Kit

2шт.

20

42Y-00-H0450

NUT

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (1A) Kit

2шт.

21

423-57-H0P18

TENSION SPRING

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (1A) Kit

2шт.

22

423-57-H0P19

GRIP

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (1A) Kit

1шт.

23

42Y-00-H2540

ADAPTER SLEEVES

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (1A) Kit

1шт.

24

423-57-H0P21

SCREW

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (1A) Kit

2шт.

25

423-57-H0P22

STIRRUP

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (1A) Kit

1шт.

26

423-57-H0P23

RAIL

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (1A) Kit

1шт.

27

423-57-H0P24

RAIL

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (1A) Kit

1шт.

28

423-57-H0P25

SCREW

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (1A) Kit

4шт.

29

01602-20825

SPRING WASHER

EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (1A) Kit

4шт.

30

423-57-H0P26

SAFETY BELT

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (1A) Kit

1шт.

31

01435-01225

SCREW

DeutschDesc: SCHRAUBE

4шт.
