Запчасти Komatsu WA320-3 БЕЗОПАСН. КАБИНА ПРИВОДRS КАБИНА

1

421-56-H0610

CAB ASSEMBLY

SN: 20221

1шт.

2

421-56-H1421

CAB ASSEMBLY

SN: 20222-UP

1шт.

3

421-56-H0P01

WINDSHIELD

EnglischBem: LAMINATED GLASS

1шт.

3

0

WINDSHIELD

EnglischBem: TOUGHENED GLASS

1шт.

3A

421-56-21130

GLASS

DeutschDesc: GLAS

2шт.

4

421-56-H0P14

PROFILE

EnglischBem: 520 CM NOTE: Pos. (4) included in Pos. (1) and (2) Kit

-26шт.

5

421-56-H0P15

FILLER SECTION

EnglischBem: 520 CM NOTE: Pos. (5) included in Pos. (1) and (2) Kit

-26шт.

6

421-56-H0P15

FILLER SECTION

EnglischBem: 425 CM NOTE: Pos. (6) included in Pos. (1) and (2) Kit

-26шт.

7

421-56-21160

GLASS

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

1шт.

8

421-56-H0P14

PROFILE

EnglischBem: 425 CM NOTE: Pos. (8) included in Pos. (1) and (2) Kit

-26шт.

9

423-00-H0560

GASKET

EnglischBem: 510 CM NOTE: Pos. (9) included in Pos. (1) and (2) Kit

-26шт.

10

421-56-H0P72

GASKET

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

1шт.

11

421-56-H0P16

PLUG

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

3шт.

12

421-56-H0P17

PLUG

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

4шт.

13

421-56-21720

PLUG

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

4шт.

14

421-56-H0P18

PROFILE

EnglischBem: 430 CM NOTE: Pos. (14) included in Pos. (1) and (2) Kit

2шт.

15

421-56-H0P19

GASKET

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

2шт.

16

421-54-15740

STRIKER

SN: 20221

1шт.

16A

421-54-15750

STRIKER

SN: 20221

1шт.

16B

421-56-H2350

STRIKER

SN: 20222-UP

2шт.

17

421-56-H0P20

UNDERLAY

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

4шт.

18

421-56-H0P21

WASHER

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

4шт.

19

423-00-H1160

SCREW

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

4шт.

20

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

21

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

22

421-56-H0P28

SCREW

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (2) Kit

4шт.

23

01010-32045

SCREW

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (2) Kit

8шт.

24

01643-32060

PLAIN WASHER

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

8шт.

25

01643-31232

PLAIN WASHER

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (2) Kit

2шт.

26

01016-51240

SCREW

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (2) Kit

2шт.

27

421-56-H0P22

FENCE

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (2) Kit

1шт.

28

419-56-H0P01

SCREW

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (2) Kit

2шт.

29

419-56-H0P02

PLAIN WASHER

EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (2) Kit

2шт.

30

421-56-H0P23

DISC

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (2) Kit

2шт.

31

421-56-21740

GASKET

EnglischBem: NOTE: Pos. (31) included in Pos. (1) and (2) Kit

1шт.

32

421-56-21700

DOOR

SN: 20221

1шт.

32A

421-56-H1960

DOOR

SN: 20222-UP

1шт.

33

421-56-21800

DOOR

SN: 20221

1шт.

33A

421-56-H1970

DOOR

SN: 20222-UP

1шт.

34

421-56-H0P24

ORIFICE PLATE

EnglischBem: NOTE: Pos. (34) included in Pos. (1) and (2) Kit

1шт.

35

01023-70516

SCREW

EnglischBem: NOTE: Pos. (35) included in Pos. (1) and (2) Kit

3шт.

36

421-56-H0P25

HOOK

EnglischBem: NOTE: Pos. (36) included in Pos. (1) and (2) Kit

1шт.

37

423-00-H1210

SCREW

EnglischBem: NOTE: Pos. (37) included in Pos. (1) and (2) Kit

2шт.

38

421-56-H0P26

MIRROR

EnglischBem: NOTE: Pos. (38) included in Pos. (1) and (2) Kit

1шт.

39

421-56-H0P27

BRACKET

EnglischBem: NOTE: Pos. (39) included in Pos. (1) and (2) Kit

1шт.

40

01643-30623

PLAIN WASHER

EnglischBem: NOTE: Pos. (40) included in Pos. (1) and (2) Kit

2шт.

41

421-56-H0P28

SCREW

EnglischBem: NOTE: Pos. (41) included in Pos. (1) and (2) Kit

2шт.

42

421-54-H1120

MIRROR

EnglischBem: NOTE: Pos. (42) included in Pos. (1) and (2) Kit

2шт.

43

421-56-H0750

BRACKET

EnglischBem: NOTE: Pos. (43) included in Pos. (1) and (2) Kit

2шт.

44

421-56-H0530

BRACKET

EnglischBem: NOTE: Pos. (44) included in Pos. (1) and (2) Kit

1шт.

45

421-56-H0540

BRACKET

EnglischBem: NOTE: Pos. (45) included in Pos. (1) and (2) Kit

1шт.

46

01435-01025

SCREW

EnglischBem: NOTE: Pos. (46) included in Pos. (1) and (2) Kit

12шт.

47

421-56-H0P73

CAP

EnglischBem: NOTE: Pos. (47) included in Pos. (1) and (2) Kit

1шт.

48

418-46-12310

ADJ SLIDE

EnglischBem: NOTE: Pos. (48) included in Pos. (1) and (2) Kit

4шт.

49

424-56-H0P04

SEALER

EnglischBem: FOR WINDSHIELD

1шт.

50

424-56-H0P03

CLEANER

EnglischBem: FOR WINDSHIELD

1шт.

51

424-56-H0P05

SEALER

EnglischBem: FOR ROOF

1шт.
