Запчасти Komatsu WA320-3 МАРКИРОВКА (АНГЛ.)(№-) МАРКИРОВКА

|$1

426-93-21570

PLATE KIT

SN: 54001-UP

1шт.

1

09653-A0641

PLATE, SAFETY,RADIATOR CAP

SN: 54001-UP

1шт.

2

09653-A0641

PLATE, SAFETY,HYDRAULIC TANK CAP

SN: 54001-UP

1шт.

3

09808-A1201

PLATE, SAFETY,BATTERY CABLE

SN: 54001-UP

2шт.

4

09161-C0641

PLATE, SAFETY,LOCK BAR

SN: 54001-UP

1шт.

5

09162-C0641

PLATE, SAFETY,KEEP OUT

SN: 54001-UP

2шт.

6

09667-A0880

PLATE, SAFETY,FAN

SN: 53001-UP

2шт.

|$8

426-93-21580

PLATE KIT

SN: 54001-UP

1шт.

7

426-93-2158003

PLATE, INSTRUCTION,FUEL

SN: 54001-UP

1шт.

8

426-93-2158004

PLATE, INSTRUCTION,RADIATOR DRAIN

SN: 54001-UP

1шт.

9

426-93-2158005

PLATE, INSTRUCTION,ENGINE OIL DRAIN

SN: 54001-UP

1шт.

10

419-93-21331

CHART, OIL

SN: 54001-UP

1шт.

11

417-93-21220

PLATE, MARK,AVANCE LOADER

SN: 53001-UP

2шт.

12

419-93-21250

PLATE, MARK,WA320

SN: 53001-UP

2шт.

13

417-93-21150

PLATE, STRIPE,L.H.

SN: 53001-UP

1шт.

14

417-93-21160

PLATE, STRIPE,R.H.

SN: 53001-UP

1шт.

15

417-93-21141

PLATE, MARK,KOMATSU

SN: 53001-UP

1шт.

16

419-93-21240

PLATE, INSTRUCTION,REAR AXLE PIVOT PIN

SN: 53001-UP

1шт.

17

09806-C0883

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 54001-UP

2шт.

18

09807-C0883

PLATE, SAFETY,KEEP OUT

SN: 54001-UP

2шт.

19

09960-01001

PLATE, MARK

SN: 53001-UP

4шт.
