Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$4
714-16-20002
TRANSMISSION ASS'Y
SN: 54143-UP
1шт.
|$5
714-16-20001
TRANSMISSION ASS'Y
SN: 52001-54142
1шт.
|$6
714-16-20000
TRANSMISSION ASS'Y
SN: 50001-52000
1шт.
|$$5
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.
-1шт.
|$8
714-16-25030
CONTROL VALVE ASS'Y
SN: (84734)-UP
1шт.
|$$7
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-61A0 TO F4350-63A0A.
-1шт.
|$10
0
CONTROL VALVE ASS'Y
SN: (83620)-(84733)
1шт.
|$11
0
CONTROL VALVE ASS'Y
SN: 50001-(83619)
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-66A0.
-1шт.
|$13
714-16-25100
VALVE ASS'Y,UPPER
SN: (83620)-UP
1шт.
|$14
0
VALVE ASS'Y,UPPER
SN: 50001-(83619)
1шт.
1
419-15-15711
BODY,UPPER
SN: 50001-UP
1шт.
2
419-15-15720
COVER
SN: 50001-UP
1шт.
3
419-15-15730
COVER
SN: 50001-UP
1шт.
4
419-15-15741
GASKET (K2)
SN: 50001-UP
1шт.
5
419-15-15751
GASKET (K2)
SN: 50001-UP
1шт.
6
419-15-15760
VALVE,PILOT
SN: 50001-UP
1шт.
7
714-16-25320
VALVE,MAIN
SN: (83620)-UP
1шт.
7
419-15-15770
VALVE,MAIN
SN: 50001-(83619)
1шт.
8
714-16-25360
VALVE,PRIORITY
SN: (83620)-UP
1шт.
8
419-15-15780
VALVE,PRIORITY
SN: 50001-(83619)
1шт.
9
419-15-15790
VALVE,ACCUMULATOR
SN: 50001-UP
1шт.
10
419-15-15810
VALVE,MODULATE
SN: 50001-UP
1шт.
11
714-11-15350
PISTON,LOAD
SN: (83620)-UP
1шт.
11
419-15-15820
PISTON,LOAD
SN: 50001-(83619)
1шт.
12
714-11-15330
PISTON,LOAD
SN: (83620)-UP
1шт.
12
419-15-15830
PISTON,LOAD
SN: 50001-(83619)
1шт.
12A
714-11-15340
PISTON,LOAD
SN: (83620)-UP
1шт.
12B
714-11-16940
SPRING
SN: (83620)-UP
1шт.
13
419-15-15840
VALVE,QUICK RETURN
SN: 50001-UP
1шт.
14
419-15-15850
PLUG,VALVE
SN: 50001-UP
1шт.
15
419-15-15860
SLEEVE,MODULATE
SN: 50001-UP
1шт.
16
419-15-15870
SHAFT,ACCUMULATOR
SN: 50001-UP
1шт.
17
714-11-16930
SPRING,MAIN
SN: (83620)-UP
1шт.
17
419-15-15910
SPRING,MAIN
SN: 50001-(83619)
1шт.
18
419-15-15920
SPRING,PRIORITY
SN: 50001-UP
1шт.
19
419-15-15940
SPRING,INNER MODULATE
SN: 50001-UP
1шт.
20
419-15-15930
SPRING,OUTER MODULATE
SN: 50001-UP
1шт.
21
419-15-15950
SPRING,OUTER ACCUMULATOR
SN: 50001-UP
1шт.
22
419-15-15960
SPRING,INNER ACCUMULATOR
SN: 50001-UP
1шт.
23
419-15-15970
SPRING,INNER ACCUMULATOR
SN: 50001-UP
1шт.
24
419-15-15880
ROD,ADJUST
SN: 50001-UP
1шт.
25
419-15-15890
PLUG,MODULATE
SN: 50001-UP
1шт.
26
419-15-15980
RETAINER,MODULATE
SN: 50001-UP
1шт.
28
419-15-15510
SPRING,CHECK
SN: 50001-UP
1шт.
29
419-15-15640
PLUG
SN: 50001-UP
1шт.
34
417-15-15842
ORIFICE,MAIN
SN: 50001-UP
1шт.
Выбрано товаров: 57
