Запчасти Komatsu WA320-3 МАРКИРОВКА (АНГЛ.) МАРКИРОВКА

|$1

421-93-21310

PLATE KIT

SN: 50001-UP

1шт.

1

0

PLATE, SAFETY,KEEP OUT

SN: 50001-UP

2шт.

2

0

PLATE, SAFETY,SAFETY BAR

SN: 50001-UP

1шт.

3

0

PLATE, SAFETY,RADIATOR CAP

SN: 50001-UP

1шт.

4

0

PLATE, SAFETY,HYDRAULIC TANK CAP

SN: 50001-UP

1шт.

5

0

PLATE, SAFETY,BATTERY CABLE

SN: 50001-UP

2шт.

6

0

PLATE, INSTRUCTION,FUEL

SN: 50001-UP

1шт.

7

0

PLATE, INSTRUCTION,ENGINE OIL DRAIN

SN: 50001-UP

1шт.

8

419-93-21260

CHART, OIL

SN: 50001-UP

1шт.

9

417-93-21220

PLATE, MARK,AVANCE LOADER

SN: 50001-UP

2шт.

10

419-93-21250

PLATE, MARK,WA320

SN: 50001-UP

2шт.

11

09690-C0315

PLATE, MARK,KOMATSU

SN: 50001-UP

1шт.

12

09806-C0880

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 50001-UP

2шт.

13

09667-A0880

PLATE, SAFETY,FAN

SN: 50001-UP

2шт.

14

09807-C0880

PLATE, SAFETY,KEEP OUT

SN: 50001-UP

2шт.

15

09960-01001

PLATE, MARK,LIFT HERE

SN: 50001-UP

4шт.

16

419-93-21240

PLATE, INSTRUCTION,REAR AXLE PIVOT PIN

SN: 50001-UP

1шт.

17

09659-53000

PLATE, SAFETY,ACCUMULATOR

SN: 50001-UP

2шт.

18

09602-10010

PLATE, NAME,(LIMITED SUPPLY)

SN: 50001-UP

1шт.

18

04418-13060

SCREW

SN: 50001-UP

4шт.

19

09637-30163

PLATE, INSTRUCTION,AIR CLEANER

SN: 50001-UP

1шт.
