Запчасти Komatsu WA320-3 ТРАНСМИССИЯ (2 И 4 МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$4

714-16-20002

TRANSMISSION ASS'Y

SN: 54143-UP

1шт.

|$5

714-16-20001

TRANSMISSION ASS'Y

SN: 52001-54142

1шт.

|$6

714-16-20000

TRANSMISSION ASS'Y

SN: 50001-52000

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0.

-1шт.

|$10

714-16-22031

CLUTCH ASS'Y,2ND AND 4TH

SN: 54143-UP

1шт.

|$11

714-16-22030

CLUTCH ASS'Y,2ND AND 4TH

SN: 50001-54142

1шт.

|$12

714-16-22130

SHAFT ASS'Y

SN: 50001-UP

1шт.

1

0

SHAFT

SN: 50001-UP

1шт.

2

419-15-12750

ORIFICE

SN: 50001-UP

1шт.

3

0

HOUSING ASS'Y

SN: 50001-UP

1шт.

4

714-16-22670

PISTON,2ND AND 4TH

SN: 50001-UP

2шт.

5

714-12-19711

DISC

SN: (84643)-UP

10шт.

5

0

DISC

SN: 50001-(84642)

10шт.

6

714-16-19730

PLATE,SEPARATE

SN: 50001-UP

12шт.

7

56D-15-12710

SPRING,WAVE

SN: (187348)-UP

10шт.

7

0

SPRING,WAVE

SN: 50001-(187347)

10шт.

8

714-12-12610

PLATE,END

SN: 50001-UP

2шт.

9

419-15-12140

RING,SNAP

SN: 50001-UP

2шт.

10

714-16-19220

RING,SEAL (K1)

SN: 50001-UP

2шт.

11

714-16-19210

RING,SEAL (K1)

SN: 50001-UP

2шт.

12

714-08-19570

WASHER,THRUST

SN: 50001-UP

3шт.

13

714-11-19510

WASHER,THRUST

SN: 50001-UP

1шт.

14

419-15-12271

BEARING,NEEDLE

SN: (85925)-UP

1шт.

14

419-15-12270

BEARING,NEEDLE

SN: 50001-(85924)

1шт.

15

714-23-19410

BEARING,NEEDLE

SN: (85925)-UP

1шт.

15

419-15-12660

BEARING,NEEDLE

SN: 50001-(85924)

1шт.

16

714-23-19430

BEARING,NEEDLE

SN: (85925)-UP

1шт.

16

419-15-13151

BEARING,NEEDLE

SN: (84860)-(85924)

1шт.

16

0

BEARING,NEEDLE

SN: 50001-(84859)

1шт.

17

714-16-22460

GEAR, 42 TEETH,2ND

SN: 50001-UP

1шт.

18

714-16-22450

GEAR, 22 TEETH,4TH

SN: 50001-UP

1шт.

19

714-16-22530

GEAR, 27 TEETH,OUTPUT

SN: 50001-UP

1шт.

20

714-12-12520

GEAR, 31 TEETH,3RD

SN: 50001-UP

1шт.

21

714-13-19310

BEARING

SN: 50001-UP

1шт.

22

714-12-19340

BEARING

SN: 54143-UP

1шт.

22

714-13-19320

BEARING

SN: 50001-54142

1шт.

23

714-12-19520

RING,SNAP

SN: 50001-UP

1шт.

24

419-15-12122

RING,SEAL (K1)

SN: 50001-UP

3шт.
