Запчасти Komatsu WA320-3 ГИДР. НАСОС.(/) РЕМ. КОМПЛЕКТЫ И COMPONENT]

|$0

705-55-24130

PUMP ASS'Y,(SAR(2)50+40+8A) THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-31A0 TO Y1600-33A0

Field_1: 15001-

1шт.

|$1

705-11-34250

PUMP ASS'Y.(SAR(2)50)

Field_1: 15001-

1шт.

1

0

BRACKET

Field_1: 15001-

1шт.

|$3

0

BUSHING

Field_1: 15001-

2шт.

2

0

CASE.GEAR

Field_1: 15001-

1шт.

3

0

CARRIER

Field_1: 15001-

1шт.

|$6

0

BUSHING

Field_1: 15001-

2шт.

4

0

GEAR.DRIVE

Field_1: 15001-

1шт.

5

0

GEAR.DRIVEN

Field_1: 15001-

1шт.

6

705-17-02612

PLATE.SIDE

Field_1: 15001-

2шт.

7

705-17-02430

RING.BACK-UP

Field_1: 15001-

2шт.

8

705-17-02460

RING.SEAL

Field_1: 15001-

2шт.

9

705-17-02360

O-RING

Field_1: 15001-

2шт.

10

04020-01024

PIN.DOWEL

Field_1: 15001-

4шт.

11

705-17-02790

BOLT

Field_1: 15001-

4шт.

12

01643-51232

WASHER

Field_1: 15001-

4шт.

13

705-17-02870

PLATE

Field_1: 15001-

1шт.

14

705-17-02830

SEAL.OIL

Field_1: 15001-

1шт.

15

04065-04018

RING.SNAP

Field_1: 15001-

1шт.

16

705-17-02330

COUPLING

Field_1: 15001-

1шт.
