Запчасти Komatsu WA320-3 КОМПРЕССОР В СБОРЕ(ДЛЯ КОНДИЦ.DITONER) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ]

|$0

425-07-21180

COMPRESSOR ASS'Y

Field_1: 15001-

1шт.

1

ND447200-1741

COMPRESSOR ASS'Y

Field_1: 15001-

1шт.

|$2

ND447300-1440

CLUTCH ASS'Y

Field_1: 15001-

1шт.

2

ND047310-7240

STATOR,MAGNET CLUTCH

Field_1: 15001-

1шт.

3

ND047350-7130

ROTOR,MAGNET CLUTCH

Field_1: 15001-

1шт.

4

ND447410-0010

HUB,CLUTCH

Field_1: 15001-

1шт.

5

ND949047-2950

BOLT,WASHER

Field_1: 15001-

6шт.

6

ND047372-0660

COVER,DUST

Field_1: 15001-

1шт.

7

ND949070-1360

RING,SNAP

Field_1: 15001-

1шт.

8

ND949070-0640

RING,SNAP

Field_1: 15001-

1шт.

9

ND949013-7480

WASHER,0.1MM,PLATE

Field_1: 15001-

1шт.

10

ND949013-7500

WASHER,0.3MM,PLATE

Field_1: 15001-

1шт.

11

ND949013-7510

WASHER,0.5MM,PLATE

Field_1: 15001-

1шт.

12

ND949048-0430

BOLT,WASHER HEAD

Field_1: 15001-

1шт.

13

ND91310-05081

SCREW,WASHER

Field_1: 15001-

1шт.

14

ND146691-4470

CLAMP

Field_1: 15001-

1шт.
