Запчасти Komatsu WA320-3 ПЕРЕДНИЙ МОСТ(КОНЕЧНАЯ ПЕРЕДАЧА) F[ТРАНСМИССИЯ]

|$0

419-22-20013

AXLE ASS'Y,FRONT THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS. F4400-01A0 TO F4400-03A0

Field_1: 15001-

1шт.

|$1

419-22-22010

FINAL DRIVE

Field_1: 15001-

1шт.

1

419-22-22730

GEAR

Field_1: 15001-

6шт.

2

417-22-22810

BEARING,CONE

Field_1: 15001-

12шт.

3

419-22-22810

CARRIER

Field_1: 15001-

2шт.

4

419-22-22950

WASHER

Field_1: 15001-

2шт.

5

419-22-12510

SHAFT

Field_1: 15001-

6шт.

6

419-22-12570

.PIN

Field_1: 15001-

6шт.

7

419-22-22710

SHAFT

Field_1: 15001-

2шт.

8

419-22-22850

BEARING

Field_1: 15001-

2шт.

9

419-22-22861

SEAL.OIL

Field_1: 15001-

2шт.

10

418-22-12850

BEARING

Field_1: 15001-

2шт.

11

419-22-22740

GEAR

Field_1: 15001-

2шт.

12

419-22-22780

.PIN

Field_1: 15001-

6шт.

13

01011-62000

BOLT

Field_1: 15001-

2шт.

14

418-22-21460

SHIM, 0.05 MM

Field_1: 15001-

4шт.

|$16

418-22-21470

SHIM, 0.2 MM

Field_1: 15001-

4шт.

|$17

418-22-21480

SHIM, 0.5 MM

Field_1: 15001-

4шт.

15

419-22-22720

SHAFT

Field_1: 15001-

2шт.
