Запчасти Komatsu WA320-3 ТРАНСМИССИЯ(ЛЕНИВЕЦ) F[ТРАНСМИССИЯ]

|$0

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$1

714-16-20001

TRANSMISSION ASS'Y THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0

Field_1: 15001-

1шт.

1

714-12-16610

GEAR,34TEETH,IDLER

Field_1: 15001-

1шт.

2

06043-06212

BEARING,BALL

Field_1: 15001-

2шт.

3

04064-06020

RING,SNAP

Field_1: 15001-

1шт.

4

421-15-13170

COVER

Field_1: 15001-

1шт.

5

07000-02105

O-RING

Field_1: 15001-

1шт.

6

01010-81230

BOLT

Field_1: 15001-

2шт.

7

01643-31232

WASHER

Field_1: 15001-

2шт.
