Запчасти Komatsu WA320-3 ТРАНСМИССИЯ(ВЫХОДНОЙ ВАЛ) F[ТРАНСМИССИЯ]

|$0

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$1

714-16-20001

TRANSMISSION ASS'Y THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-68A0

Field_1: 15001-

1шт.

1

714-16-24520

SHAFT,OUTPUT

Field_1: 15001-

1шт.

2

714-12-14620

GEAR,36TEETH,OUPPUT

Field_1: 15001-

1шт.

3

04064-07525

RING,SNAP

Field_1: 15001-

1шт.

4

06002-30213

BEARING,

Field_1: 15001-

1шт.

5

06002-32013

BEARING,

Field_1: 15001-

1шт.

6

714-12-14910

COVER,GEAR

Field_1: 15001-

1шт.

7

01010-81225

BOLT

Field_1: 15001-

2шт.

8

01643-31232

WASHER

Field_1: 15001-

2шт.

9

714-16-24110

COUPLING,FRONT

Field_1: 15001-

1шт.

|$11

714-13-14320

DEFLECTOR

Field_1: 15001-

1шт.

10

423-22-21240

WASHER

Field_1: 15001-

1шт.

11

01011-62020

BOLT

Field_1: 15001-

1шт.

12

07000-05055

O-RING

Field_1: 15001-

1шт.

13

714-12-19121

SEAL,OIL

Field_1: 15001-

1шт.

14

714-12-19121

SEAL,OIL

Field_1: 15001-

1шт.

15

714-12-19170

SEAL,DUST

Field_1: 15001-

1шт.

16

714-12-19170

SEAL,DUST

Field_1: 15001-

1шт.

17

714-16-28610

HUB

Field_1: 15001-

1шт.

18

714-16-14122

COUPLING,REAR

Field_1: 15001-

1шт.

|$21

714-11-14320

DEFLECTOR

Field_1: 15001-

1шт.

19

0

SHIM ASS'Y

Field_1: 15001-

1шт.

|$23

714-13-14271

SHIM,0.05MM,R.H.

Field_1: 15001-

3шт.

|$24

714-13-14291

SHIM,0.20MM,R.H.

Field_1: 15001-

2шт.

|$25

714-13-14280

SHIM,0.50MM,R.H.

Field_1: 15001-

4шт.

|$26

714-13-14370

SHIM,0.05MM,L.H.

Field_1: 15001-

3шт.

|$27

714-13-14390

SHIM,0.20MM,L.H.

Field_1: 15001-

2шт.

|$28

714-13-14380

SHIM,0.50MM,L.H.

Field_1: 15001-

4шт.

20

714-13-18311

COVER

Field_1: 15001-

1шт.

21

714-16-28320

RETAINER

Field_1: 15001-

1шт.

22

714-13-18691

GASKET

Field_1: 15001-

1шт.
