Запчасти Komatsu WA320-3 active МОСТ INSERT, ПЕРЕДНИЙ МОСТ 8 ПЕРЕДНИЙ МОСТ

Схема запчастей Komatsu WA320-3 active - МОСТ INSERT, ПЕРЕДНИЙ МОСТ 8 ПЕРЕДНИЙ МОСТ
3
1
2
4
5
6
7
8
8
7
9
10
10
11
12
13
14
15
18
19
20
21
22
23
24
25
26
27
28
29
31
30
32
33
34
35
38
39
40
41
35
38
34
33
32
40
39
42
44
43

Артикул

Название

Примечание

Количество

1

419-22-21050

AXLE INSERT

EnglischBem: L S D

1шт.

2

419-22-21001

AXLE INSERT

EnglischBem: T P D

1шт.

3

419-22-23112

HOUSING

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (2) Kit

1шт.

4

07043-50211

PLUG

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (2) Kit

2шт.

5

07044-13620

PLUG

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

1шт.

6

07002-03634

O-RING

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

1шт.

7

07040-12012

PLUG

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

2шт.

8

07002-02034

O-RING

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

2шт.

9

04020-01228

DOWEL

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

4шт.

10

419-22-21200

BEVEL GEAR

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

1шт.

11

419-22-21130

HOUSING

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

1шт.

12

419-22-11810

BEARING

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

1шт.

13

419-22-11860

DISTANCE PIECE

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

1шт.

14

07000-05190

O-RING

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (2) Kit

1шт.

15

419-22-21360

DISC

EnglischBem: THICKNESS 0,05 MM NOTE: Pos. (15) included in Pos. (1) and (2) K

3шт.

16

419-22-21370

DISC

EnglischBem: THICKNESS 0,20 MM NOTE: Pos. (16) included in Pos. (1) and (2) K

2шт.

17

419-22-21380

DISC

EnglischBem: THICKNESS 0,30 MM NOTE: Pos. (17) included in Pos. (1) and (2) K

2шт.

18

419-22-21390

DISC

EnglischBem: THICKNESS 0,80 MM NOTE: Pos. (18) included in Pos. (1) and (2) K

1шт.

19

01010-61440

SCREW

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

10шт.

20

01643-31445

PLAIN WASHER

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (2) Kit

10шт.

21

419-22-11820

TAPER.ROLLER BEARING

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (2) Kit

1шт.

22

418-22-21330

SHAFT SEAL

EnglischBem: NOTE: Pos. (22) included in Pos. (1) and (2) Kit

1шт.

23

418-22-21310

DEFLECTOR

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (2) Kit

1шт.

24

419-22-21230

DRIVE FLANGE

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (2) Kit

1шт.

25

423-22-11240

DISC

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (2) Kit

1шт.

26

419-09-H2110

O-RING

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (2) Kit

1шт.

27

01011-61615

SCREW

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (2) Kit

1шт.

28

419-22-21500

HOUSING ASSEMBLY

EnglischBem: T P D

1шт.

|$45

HOUSING ASSEMBLY

DeutschDesc: GEHAEUSE KPL

-3шт.

29

419-22-27101

DIFFERENTIAL

EnglischBem: L S D

1шт.

|$46

DIFFERENTIAL

DeutschDesc: DIFFERENTIAL

-3шт.

30

01010-61240

SCREW

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (2) Kit

20шт.

31

01643-31232

PLAIN WASHER

EnglischBem: NOTE: Pos. (31) included in Pos. (1) and (2) Kit

20шт.

32

419-22-21160

DRIVING

EnglischBem: NOTE: Pos. (32) included in Pos. (1) and (2) Kit

2шт.

33

419-22-11850

TAPER.ROLLER BEARING

EnglischBem: NOTE: Pos. (33) included in Pos. (1) and (2) Kit

2шт.

34

419-33-11430

RING

EnglischBem: NOTE: Pos. (34) included in Pos. (1) and (2) Kit

2шт.

35

419-22-21460

DISC

EnglischBem: THICKNESS 0,05 MM NOTE: Pos. (35) included in Pos. (1) and (2) K

6шт.

36

419-22-21470

DISC

EnglischBem: THICKNESS 0,20 MM NOTE: Pos. (36) included in Pos. (1) and (2) K

3шт.

37

419-22-21480

DISC

EnglischBem: THICKNESS 0,30 MM NOTE: Pos. (37) included in Pos. (1) and (2) K

3шт.

38

419-22-21490

DISC

EnglischBem: THICKNESS 0,80 MM NOTE: Pos. (38) included in Pos. (1) and (2) K

2шт.

39

01010-61240

SCREW

EnglischBem: NOTE: Pos. (39) included in Pos. (1) and (2) Kit

16шт.

40

01643-31232

PLAIN WASHER

EnglischBem: NOTE: Pos. (40) included in Pos. (1) and (2) Kit

16шт.

41

04020-01228

DOWEL

EnglischBem: NOTE: Pos. (41) included in Pos. (1) and (2) Kit

2шт.

42

419-22-23120

COVER

EnglischBem: NOTE: Pos. (42) included in Pos. (1) and (2) Kit

1шт.

43

01010-61240

SCREW

EnglischBem: NOTE: Pos. (43) included in Pos. (1) and (2) Kit

20шт.

44

01643-31232

PLAIN WASHER

EnglischBem: NOTE: Pos. (44) included in Pos. (1) and (2) Kit

20шт.

Выбрано товаров: 46
