Запчасти Komatsu WA320-1LC ТОПЛИВОПРОВОД. ТОПЛИВН. СИСТЕМА

1

1240 215 H1

SEAL, BANJO CONNECTOR

1шт.

2

1240 334 H1

SCREW, BANJO CONNECTOR

7шт.

3

1270 368 H91

MANIFOLD, FUEL

1шт.

4

1241 038 H1

TUBE, FUEL SUPPLY - CYLINDER NO. 1

1шт.

5

1241 039 H1

TUBE, FUEL SUPPLY - CYLINDER NO. 2

1шт.

6

1241 040 H1

TUBE, FUEL SUPPLY - CYLINDER NO. 3

1шт.

7

1241 235 H1

TUBE, FUEL SUPPLY - CYLINDER NO. 4

1шт.

8

1241 042 H1

TUBE, FUEL SUPPLY - CYLINDER NO. 5

1шт.

9

1241 043 H1

TUBE, FUEL SUPPLY - CYLINDER NO. 6

1шт.

10

1240 769 H1

BRACE, TUBE

2шт.

|$10

1240 260 H1

CLAMP, TUBE BRACE

2шт.

|$11

1270 369 H1

ISOLATOR, VIBRATION

4шт.

|$12

1240 225 H1

BOLT

4шт.

|$13

1240 227 H1

WASHER, PLAIN

4шт.

11

SCREW, BANJO CONNECTOR (SEE PG E4-010)

-29шт.

12

1240 203 H1

WASHER, PLAIN

2шт.

|$16

1240 740 H1

SCREW ASSY, BANJO CONNECTOR

1шт.

13

1241 244 H1

SCREW, BANJO CONNECTOR

1шт.

14

NSS

BOLT W/WASHER

1шт.

15

1241 270 H1

TUBE, FUEL SUPPLY

1шт.

16

1294 806 H1

CLIP

1шт.

17

1294 807 H1

WASHER, PLAIN

2шт.

18

1241 204 H2

SCREW, BANJO CONNECTOR

1шт.

19

1241 245 H1

FITTING, BANJO

1шт.

20

1241 151 H1

BOLT

2шт.

21

1259 511 H2

SOLENOID, FUEL PUMP - 24V

1шт.

22

1280 607 H1

BRACKET, SOLENOID

1шт.

23

1240 966 H1

BOLT

2шт.

24

PUMP, FUEL (SEE PG E4-008)

-29шт.

25

INJECTOR (SEE PG E4-012)

-29шт.

26

1240 215 H1

SEAL, BANJO CONNECTOR

1шт.
