Запчасти Komatsu WA320-1LC КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ

|$0

1240 968 H93

CRANKSHAFT ASSEMBLY

1шт.

1

NSS

CRANKSHAFT

1шт.

2

1240 259 H1

PIN, DOWEL

1шт.

3

1241 064 H3

GEAR, CRANKSHAFT

1шт.

N/I

1241 184 H2

KIT, MAIN BEARING - STD

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

N/I

1294 793 H91

KIT, MAIN BEARING - 0.25MM OVERSIZE

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

N/I

1294 794 H91

KIT, MAIN BEARING - 0.50MM OVERSIZE

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

N/I

1294 795 H91

KIT, MAIN BEARING - 0.75MM OVERSIZE

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

N/I

1294 796 H91

KIT, MAIN BEARING - 1.00MM OVERSIZE

1шт.

4

NSS

BEARING, MAIN UPPER

6шт.

5

NSS

BEARING, MAIN THRUST

1шт.

6

NSS

BEARING, MAIN LOWER

7шт.

7

1295 465 H92

SLEEVE, WEAR - FRONT CRANK

1шт.

8

1240 762 H1

SLEEVE, WEAR - REAR CRANK

1шт.
