Запчасти Komatsu WA320-1LC МАРКИРОВКА (АНГЛ.) ТАБЛИЧКИS МАРКИРОВКАS, ИНСТРУМЕНТ & КОМПЛЕКТS

|$46

-1шт.

|$1

PERSONAL SAFETY PRODUCT GRAPHICS:

-1шт.

1

161 177 H6

CAUTION - LADDERS

2шт.

2

737 993 C2

CAUTION - ROLLOVER

1шт.

3

204 166 C2

CAUTION - PRESSURIZED COOLING SYSTEM

1шт.

4

2754 473 R3

CAUTION - HYDRAULIC RESERVOIR

1шт.

5

421-93-A1180

CAUTION - BATTERY INSTALLATION

2шт.

6

421-93-A1160

CAUTION - BATTERY CHARGING

2шт.

7

421-93-A1120

CAUTION - TRANSMISSION OIL LEVEL

1шт.

8

NOT USED

-1шт.

9

421-93-A1130

CAUTION - OPERATOR INSTRUCTIONS

1шт.

10

421-93-A1170

WARNING - OPERATOR MANUAL

1шт.

11

421-93-A1140

DANGER - FRAME LOCKING BAR

1шт.

12

421-93-A1210

CAUTION - ENGINE FAN

2шт.

13

423-93-11420

DANGER - NO CLEARANCE - ARTICULATION

2шт.

14

1170 724 C2

EMERGENCY EXIT (ON WINDOW SILL)

1шт.

|$47

-1шт.

|$17

INSTRUCTIONAL PRODUCT GRAPHICS:

-1шт.

15

419-93-11760

LUBE CHART

1шт.

16

1124 685 C2

DIESEL FUEL

1шт.

17

09685-00004

CONTROL LEVER LOCK

1шт.

18

09683-30070

STARTER SWITCH

1шт.

19

421-93-11132

BUCKET POSTION

1шт.

20

1120 093 C2

LIFT AND TIE DOWN LOCATION

4шт.

21

419-93-11911

ELECTRONIC MONITOR DECAL (LOCATED ON WINDOW)

1шт.

22

421-93-A1110

ETHER START

1шт.

23

421-93-A1220

TRANSMISSION OIL TEMP

1шт.

24

419-93-11770

FUSE IDENTIFICATION

1шт.

25

419-93-11391

FUSE ACCESSORIES IDENTIFICATION

1шт.

26

1104 217 C2

ENGINE OIL DRAIN

1шт.

27

NOT USED

-1шт.

|$48

-1шт.

|$32

IDENTIFICATION PRODUCT GRAPHICS:

-1шт.

28

09690-C0315

IN KOMATSU IN ON GRILL

1шт.

29

419-93-11471

IN WA320 IN MARK

2шт.

30

09690-C0224

IN KOMATSU IN MARK-CAB

2шт.

31

419-93-A1230

DECAL - LEFT HAND

1шт.

32

419-93-A1240

DECAL - RIGHT HAND

1шт.

N/I

419-93-A1260

DECAL - STRIPE TOP

1шт.

|$49

-1шт.

|$40

MISCELLANEOUS PRODUCT GRAPHICS:

-1шт.

33

425-93-A1141

I.D. PLATE

1шт.

34

04418-13060

SCREW

4шт.

35

419-93-A1250

TAPE STRIPE

2шт.

|$50

-1шт.

|$45

MEMORANDUM PAGE

-1шт.
