Запчасти Komatsu WA300L-3 ТРАНСМИССИЯ (1 И 3 МУФТА) ТРАНСМИССИЯ

|$1

714-16-20001

TRANSMISSION ASS'Y

SN: 53001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.

-1шт.

|$4

714-16-22020

CLUTCH ASS'Y,1ST AND 3RD

SN: 53001-UP

1шт.

|$5

714-16-22120

SHAFT ASS'Y

SN: 53001-UP

1шт.

1

0

SHAFT

SN: 53001-UP

1шт.

2

0

HOUSING ASS'Y

SN: 53001-UP

1шт.

3

714-16-22660

PISTON,1ST AND 3RD

SN: 53001-UP

2шт.

4

714-12-19711

DISC

SN: 53001-UP

10шт.

5

714-16-19730

PLATE,SEPARATE

SN: 53001-UP

12шт.

6

56D-15-12710

SPRING,WAVE

SN: (187348)-UP

10шт.

6

0

SPRING,WAVE

SN: 53001-(187347)

10шт.

7

714-12-12610

PLATE,END

SN: 53001-UP

2шт.

8

419-15-12140

RING,SNAP

SN: 53001-UP

2шт.

9

714-16-19230

RING,SEAL (K1)

SN: 53001-UP

2шт.

10

714-16-19210

RING,SEAL (K1)

SN: 53001-UP

2шт.

11

714-08-19570

WASHER,THRUST

SN: 53001-UP

2шт.

12

714-08-19560

WASHER,THRUST

SN: 53001-UP

2шт.

13

419-15-12660

BEARING,NEEDLE

SN: 53001-UP

3шт.

14

714-12-12740

SPACER

SN: 53001-UP

1шт.

15

714-12-12720

SPACER

SN: 53001-UP

1шт.

16

714-12-19510

RING,SNAP

SN: 53001-UP

1шт.

17

714-16-22440

GEAR, 40 TEETH,3RD

SN: 53001-UP

1шт.

18

714-16-22430

GEAR, 21 TEETH,1ST

SN: 53001-UP

1шт.

19

714-16-22510

GEAR, 29 TEETH

SN: 53001-UP

1шт.

20

714-16-29340

BEARING

SN: 53001-UP

1шт.

21

714-12-19330

BEARING,BALL

SN: 53001-UP

1шт.

22

419-15-12122

RING,SEAL (K1)

SN: 53001-UP

3шт.
