Запчасти Komatsu WA300L-3 ТРАНСМИССИЯ (МУФТА ВПЕРЕД/РЕВЕРС) ТРАНСМИССИЯ

|$1

714-16-20001

TRANSMISSION ASS'Y

SN: 53001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-67A0.

-1шт.

|$5

714-16-22010

CLUTCH ASS'Y,FORWARD AND REVERSE

SN: 53001-UP

1шт.

|$6

714-16-22110

SHAFT ASS'Y

SN: 53001-UP

1шт.

1

0

SHAFT,INPUT

SN: 53001-UP

1шт.

2

0

CYLINDER

SN: 53001-UP

1шт.

3

714-16-22360

HOUSING ASS'Y

SN: 53001-UP

1шт.

4

714-16-22650

PISTON,FORWARD AND REVERSE

SN: 53001-UP

2шт.

5

714-12-19711

DISC

SN: 53001-UP

18шт.

6

714-16-19730

PLATE,SEPARATE

SN: 53001-UP

20шт.

7

56D-15-12710

SPRING,WAVE

SN: (187348)-UP

18шт.

7

0

SPRING,WAVE

SN: 53001-(187347)

18шт.

8

714-12-12610

PLATE,END

SN: 53001-UP

2шт.

9

419-15-12140

RING,SNAP

SN: 53001-UP

4шт.

10

714-08-19230

RING,SEAL (K1)

SN: 53001-UP

2шт.

11

714-16-19210

RING,SEAL (K1)

SN: 53001-UP

2шт.

12

714-11-19510

WASHER,THRUST

SN: 53001-UP

2шт.

13

714-08-19560

WASHER,THRUST

SN: 53001-UP

2шт.

14

419-15-12270

BEARING,NEEDLE

SN: 53001-UP

3шт.

15

714-11-12710

SPACER

SN: 53001-UP

2шт.

16

714-13-19310

BEARING

SN: 53001-UP

1шт.

17

714-13-19310

BEARING

SN: 53001-UP

1шт.

18

714-16-22420

GEAR, 38 TEETH,FORWARD

SN: 53001-UP

1шт.

19

714-16-22410

GEAR, 23 TEETH,REVERSE

SN: 53001-UP

1шт.

20

419-15-12122

RING,SEAL (K1)

SN: 53001-UP

4шт.
