Запчасти Komatsu WA300-3A-X КОВШ(№-) КАТАЛОГИ ЗЧ

|$$1

2.3M3 BUCKET

-1шт.

|$$2

2.5M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

|1

419-70-22100

BUCKET ASS'Y

SN: 50001-UP

1шт.

1

419-70-22110

BUCKET

SN: 50001-UP

1шт.

2

419-70-22130

PLATE (WELDED)

SN: 50001-UP

2шт.

3

419-70-12122

EDGE (WELDED)

SN: 50001-UP

1шт.

4

419-70-22140

PLATE

SN: 50001-UP

2шт.

5

02090-11470

BOLT

SN: 50001-UP

4шт.

6

02290-11422

NUT

SN: 50001-UP

4шт.

7

01643-32260

WASHER

SN: 50001-UP

4шт.

|$$11

HIGH LIFT BUCKET

-1шт.

|$$12

2.0M3 BUCKET

-1шт.

|$$13

2.2M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

|1

419-821-2100

BUCKET ASS'Y

SN: 50001-UP

1шт.

1

419-821-2110

BUCKET

SN: 50001-UP

1шт.

2

419-806-2130

PLATE (WELDED)

SN: 50001-UP

2шт.

3

419-70-12122

EDGE (WELDED)

SN: 50001-UP

1шт.

4

419-70-22140

PLATE

SN: 50001-UP

2шт.

5

02090-11470

BOLT

SN: 50001-UP

4шт.

6

02290-11422

NUT

SN: 50001-UP

4шт.

7

01643-32260

WASHER

SN: 50001-UP

4шт.

|$$22

EXCAVATING BUCKET

-1шт.

|$$23

2.0M3 BUCKET

-1шт.

|$$24

2.2M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

|8

419-806-2100

BUCKET ASS'Y

SN: 50001-UP

1шт.

8

419-806-2110

BUCKET

SN: 50001-UP

1шт.

9

419-806-2130

PLATE (WELDED)

SN: 50001-UP

2шт.

10

419-70-12122

EDGE (WELDED)

SN: 50001-UP

1шт.

11

419-806-2150

PLATE (WELDED)

SN: 50001-UP

2шт.

12

419-70-22140

PLATE

SN: 50001-UP

2шт.

13

02090-11470

BOLT

SN: 50001-UP

4шт.

14

02290-11422

NUT

SN: 50001-UP

4шт.

15

01643-32260

WASHER

SN: 50001-UP

4шт.

|$$34

LIGHT MATERIAL{(FOR COUPLER BUCKET)}

-1шт.

|$$35

2.3M3 BUCKET

-1шт.

|$$36

2.5M3 BUCKET{(WITH BOLT ON CUTTING EDGE)}

-1шт.

16

419-840-1102

BUCKET

SN: 50001-UP

1шт.

17

419-70-12131

PLATE (WELDED)

SN: 50001-UP

2шт.

18

419-70-12122

EDGE (WELDED)

SN: 50001-UP

1шт.

19

419-70-12154

PLATE,L.H. (WELDED)

SN: 50001-UP

1шт.

20

419-70-12164

PLATE,R.H. (WELDED)

SN: 50001-UP

1шт.
