Запчасти Komatsu WA300-3A ТРАНСМИССИЯ (2 И 4 МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-16-10012

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|1

714-16-10011

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|1

714-16-10033

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|1

714-16-10032

TRANSMISSION ASS'Y,(FOR SNOW REMOVING)

SN: 53001-54000

1шт.

|$$6

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|1

714-16-12030

CLUTCH ASS'Y,2ND AND 4TH

SN: 53001-UP

1шт.

1

714-16-12130

SHAFT ASS'Y

SN: 53001-UP

1шт.

2

714-12-12660

PISTON,2ND AND 4TH

SN: 53001-UP

2шт.

3

714-12-19711

DISC

SN: (84640)-UP

10шт.

|3

0

DISC

SN: 53001-(84639)

10шт.

4

714-16-19730

PLATE,SEPARATE

SN: 53001-UP

12шт.

5

419-15-12133

SPRING,WAVE

SN: 53001-UP

10шт.

6

714-12-12610

PLATE,END

SN: 53001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 53001-UP

2шт.

8

714-16-19220

RING,SEAL

SN: 53001-UP

2шт.

9

714-16-19210

RING,SEAL

SN: 53001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 53001-UP

4шт.

11

714-23-19430

BEARING,NEEDLE

SN: (85905)-UP

3шт.

|11

0

BEARING

SN: (84864)-(85904)

3шт.

|11

0

BEARING,NEEDLE

SN: 53001-(84865)

3шт.

12

714-12-12460

GEAR¤ 27 TEETH,2ND

SN: 53001-UP

1шт.

13

714-12-12450

GEAR¤ 22 TEETH,4TH

SN: 53001-UP

1шт.

14

714-12-12530

GEAR¤ 27 TEETH

SN: 53001-UP

1шт.

15

714-12-12540

GEAR¤ 31 TEETH

SN: 53001-UP

1шт.

16

714-12-19380

BEARING

SN: (85418)-UP

1шт.

|16

0

BEARING

SN: 53001-(85417)

1шт.

17

714-12-19350

BEARING

SN: 53001-UP

1шт.

18

714-12-12790

SPACER

SN: 53001-UP

1шт.

19

04066-00065

RING,SNAP

SN: 53001-UP

1шт.

20

04077-00080

RING

SN: 53001-UP

1шт.

21

714-12-12920

SPACER

SN: 53001-UP

1шт.

22

419-15-12122

RING,SEAL

SN: 53001-UP

3шт.
