Запчасти Komatsu WA300-3A ТРАНСМИССИЯ (МУФТА ВПЕРЕД/РЕВЕРС) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-16-10012

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|1

714-16-10011

TRANSMISSION ASS'Y

SN: 53001-54000

1шт.

|1

714-16-10033

TRANSMISSION ASS'Y

SN: 54001-UP

1шт.

|1

714-16-10032

TRANSMISSION ASS'Y,(FOR SNOW REMOVING)

SN: 53001-54000

1шт.

|$$6

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|1

714-16-12040

CLUTCH ASS'Y,FORWARD AND REVERSE

SN: 53001-UP

1шт.

1

714-16-12140

SHAFT ASS'Y

SN: 53001-UP

1шт.

2

714-16-12360

HOUSING

SN: 53001-UP

1шт.

3

714-16-12650

PISTON,FORWARD AND REVERSE

SN: 53001-UP

2шт.

4

714-12-19711

DISC

SN: (84640)-UP

18шт.

|4

0

DISC

SN: 53001-(84639)

18шт.

5

714-16-19730

PLATE,SEPARATE

SN: 53001-UP

20шт.

6

419-15-12133

SPRING,WAVE

SN: 53001-UP

18шт.

7

714-12-12610

PLATE,END

SN: 53001-UP

2шт.

8

419-15-12140

RING,SNAP

SN: 53001-UP

4шт.

9

714-08-19230

RING,SEAL

SN: 53001-UP

2шт.

10

714-16-19210

RING,SEAL

SN: 53001-UP

2шт.

11

714-08-19560

WASHER,THRUST

SN: 53001-UP

1шт.

12

714-11-19510

WASHER,THRUST

SN: 53001-UP

1шт.

13

419-15-12640

BEARING,THRUST

SN: 53001-UP

2шт.

14

714-23-19420

BEARING,NEEDLE

SN: (85905)-UP

1шт.

|14

0

BEARING,NEEDLE

SN: 53001-(85904)

1шт.

15

419-15-12271

BEARING,NEEDLE

SN: (85905)-UP

2шт.

|15

0

BEARING,NEEDLE

SN: 53001-(85904)

2шт.

16

714-12-12740

SPACER

SN: 53001-UP

1шт.

17

714-12-12710

SPACER

SN: 53001-UP

1шт.

18

714-12-19330

BEARING

SN: 53001-UP

1шт.

19

06033-02210

BEARING

SN: 53001-UP

1шт.

20

714-12-12420

GEAR¤ 38 TEETH,FORWARD

SN: 53001-UP

1шт.

21

714-12-12410

GEAR¤ 23 TEETH,REVERSE

SN: 53001-UP

1шт.

22

714-12-12760

WASHER

SN: 53001-UP

2шт.

23

419-15-12650

WASHER,THRUST

SN: 53001-UP

2шт.

24

714-12-12930

SPACER

SN: 53001-UP

1шт.

25

04066-00050

RING,SNAP

SN: 53001-UP

1шт.

26

714-07-12290

RING,SEAL

SN: 53001-UP

4шт.
