Артикул
Название
Примечание
Количество
|$1
363-876-3131
VALVE ASS'Y
SN: 26001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1682-01A0 AND Y1682-02A0.
-1шт.
|$$3
THE KAYABA KOGYO PART NUMBER IS THAT KB IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
363-43-38470
PLATE
SN: 26001-UP
2шт.
|$5
42A-64-13160
INLET SECTION ASS'Y
SN: 26001-UP
1шт.
2
KB21011-30336
HOUSING,INLET
SN: 26001-UP
1шт.
3
KB21001-00106
O-RING
SN: 26001-UP
1шт.
|$8
363-876-3120
SPOOL SECTION ASS'Y
SN: 26001-UP
1шт.
4
0
HOUSING
SN: 26001-UP
1шт.
5
KB21011-32404
POPPET
SN: 26001-UP
1шт.
7
KB21001-00106
O-RING
SN: 26001-UP
1шт.
8
0
SPOOL
SN: 26001-UP
1шт.
9
KB21001-00689
O-RING
SN: 26001-UP
2шт.
10
KB21011-32801
WIPER
SN: 26001-UP
2шт.
11
KB21011-31702
PLATE
SN: 26001-UP
2шт.
12
KB91111-60102
SCREW
SN: 26001-UP
2шт.
13
KB21011-30702
SEAT,SPRING
SN: 26001-UP
2шт.
14
KB21011-30612
SPRING
SN: 26001-UP
1шт.
15
KB21011-30507
SCREW,CAP
SN: 26001-UP
1шт.
16
KB21011-31011
CAP
SN: 26001-UP
1шт.
17
KB92703-06181
BOLT,HEAD
SN: 26001-UP
2шт.
|$23
363-64-33220
SPOOL SECTION ASS'Y
SN: 26001-UP
1шт.
18
0
HOUSING
SN: 26001-UP
1шт.
19
KB21011-32404
POPPET
SN: 26001-UP
1шт.
21
KB21001-00106
O-RING
SN: 26001-UP
1шт.
22
0
SPOOL
SN: 26001-UP
1шт.
23
KB21001-00689
O-RING
SN: 26001-UP
1шт.
24
KB21011-32801
WIPER
SN: 26001-UP
1шт.
25
KB21011-31702
PLATE
SN: 26001-UP
1шт.
26
KB91111-60102
SCREW
SN: 26001-UP
2шт.
27
KB21011-31856
SLEEVE
SN: 26001-UP
1шт.
28
KB21001-00689
O-RING
SN: 26001-UP
1шт.
29
KB95151-02800
O-RING
SN: 26001-UP
1шт.
30
KB21011-30702
SEAT,SPRING
SN: 26001-UP
2шт.
31
KB21011-30630
SPRING
SN: 26001-UP
1шт.
32
KB21011-32801
WIPER
SN: 26001-UP
1шт.
33
KB21011-31707
PLATE
SN: 26001-UP
1шт.
34
KB21011-30565
PIN
SN: 26001-UP
1шт.
35
KB93317-05322
NUT
SN: 26001-UP
1шт.
36
KB21011-33453
PLATE
SN: 26001-UP
1шт.
37
KB21001-01456
BOLT,HEAD
SN: 26001-UP
1шт.
38
KB95111-02550
O-RING
SN: 26001-UP
1шт.
39
KB21001-01458
SHIM
SN: 26001-UP
-2шт.
40
KB25113-30127
TUBE,COIL
SN: 26001-UP
1шт.
41
KB95111-02550
O-RING
SN: 26001-UP
1шт.
42
KB21011-31095
CAP
SN: 26001-UP
1шт.
43
KB21001-01457
BOLT,HEAD
SN: 26001-UP
2шт.
44
42A-64-13270
PLUG
SN: 26001-UP
1шт.
45
42A-64-13280
O-RING
SN: 26001-UP
1шт.
46
42A-64-13220
RELIEF VALVE ASS'Y,MAIN
SN: 26001-UP
1шт.
48
42A-64-13230
RELIEF VALVE ASS'Y,OVERLOAD
SN: 26001-UP
4шт.
50
42A-64-13250
PLUG,(FOR SHIPPING)
SN: 26001-UP
6шт.
Выбрано товаров: 56
