Запчасти Komatsu WA30-5 ОСНОВН. НАСОС (ПОРШЕНЬ НАСОС ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

362-17-41402

PUMP ASS'Y,(A4VG28DA-929-0)

SN: 26001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-01A0 TO Y1610-07A0.

-1шт.

|$3

UCBA041S9146-0

PUMP ASS'Y,PISTON

SN: 26001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-02A0 T0 Y1610-06A0.

-1шт.

1

UC4704375889

ROTARY ASS'Y

SN: 26001-UP

1шт.

2

UC4704340893

CYLINDER ASS'Y,LEANING

SN: 26001-UP

1шт.

3

UC4100571211

COVER ASS'Y

SN: 26001-UP

1шт.

4

UC4100368143

RELIEF VALVE ASS'Y,HIGH PRESSURE

SN: 26001-UP

2шт.

5

UC4704336674

RELIEF VALVE ASS'Y,LOW PRESSURE

SN: 26001-UP

1шт.

6

0

CONTROL VALVE ASS'Y

SN: 26001-UP

1шт.

7

UC4100368152

DA CURTRIDGE ASS'Y

SN: 26001-UP

1шт.

8

UC1100355618

HOUSING

SN: 26001-UP

1шт.

8

0

HOUSING

SN: 26001-UP

1шт.

9

UC1704260763

COVER

SN: 26001-UP

1шт.

10

UC1704352779

PACKING

SN: 26001-UP

1шт.

11

01252-30612

BOLT

SN: 26001-UP

11шт.

12

UC1100389629

PLUG

SN: 26001-UP

2шт.

13

UC1704142279

PIN

SN: 26001-UP

2шт.

14

UC1700023809

SPRING

SN: 26001-UP

2шт.

15

UC1302193049

PIN,SPRING

SN: 26001-UP

2шт.

16

02891-02009

O-RING

SN: 26001-UP

2шт.

17

UC1100362276

PIN

SN: 26001-UP

1шт.

18

UC1100357779

NUT

SN: 26001-UP

1шт.

19

UC1701516926

PLUG

SN: 26001-UP

1шт.

20

UC1301177009

O-RING

SN: 26001-UP

1шт.

21

UC1100350071

PLUG

SN: 26001-UP

2шт.

21

418-62-11620

O-RING

SN: 26001-UP

1шт.

22

UC1607054546

PLUG

SN: 26001-UP

3шт.

22

416-62-11480

O-RING

SN: 26001-UP

1шт.

23

UC1700843025

SEAL

SN: 26001-UP

2шт.
