Артикул
Название
Примечание
Количество
|1
363-N39-4260
VALVE ASS'Y
SN: 15001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1683-01A1 AND Y1683-02A1.
-1шт.
|$$3
THE KAYABA KOGYO PART NUMBER IS THAT KB IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
42A-64-13160
INLET SECTION ASS'Y
SN: 15001-UP
1шт.
1
KB21011-30336
HOUSING,INLET
SN: 15001-UP
1шт.
2
KB21001-00106
O-RING
SN: 15001-UP
1шт.
|3
363-876-3120
SPOOL SECTION ASS'Y
SN: 15001-UP
1шт.
3
0
HOUSING
SN: 15001-UP
1шт.
4
KB21011-32404
POPPET
SN: 15001-UP
1шт.
6
KB21001-00106
O-RING
SN: 15001-UP
1шт.
7
0
SPOOL
SN: 15001-UP
1шт.
8
KB21001-00689
O-RING
SN: 15001-UP
2шт.
9
KB21011-32801
WIPER
SN: 15001-UP
2шт.
10
KB21011-31702
PLATE
SN: 15001-UP
2шт.
11
KB91111-60102
SCREW
SN: 15001-UP
2шт.
12
KB21011-30702
SEAT,SPRING
SN: 15001-UP
2шт.
13
KB21011-30612
SPRING
SN: 15001-UP
1шт.
14
KB21011-30507
SCREW,CAP
SN: 15001-UP
1шт.
15
KB21011-31011
CAP
SN: 15001-UP
1шт.
16
KB92703-06181
BOLT,HEAD
SN: 15001-UP
2шт.
|17
363-64-33120
SPOOL SECTION ASS'Y
SN: 15001-UP
1шт.
17
0
HOUSING
SN: 15001-UP
1шт.
18
KB21011-32404
POPPET
SN: 15001-UP
1шт.
20
KB21001-00106
O-RING
SN: 15001-UP
1шт.
21
0
SPOOL
SN: 15001-UP
1шт.
22
KB21001-00689
O-RING
SN: 15001-UP
1шт.
23
KB21011-32801
WIPER
SN: 15001-UP
1шт.
24
KB21011-31702
PLATE
SN: 15001-UP
1шт.
25
KB91111-60102
SCREW
SN: 15001-UP
2шт.
26
KB21011-31856
SLEEVE
SN: 15001-UP
1шт.
27
KB21001-00689
O-RING
SN: 15001-UP
1шт.
28
KB95151-02800
O-RING
SN: 15001-UP
1шт.
29
KB21011-30702
SEAT,SPRING
SN: 15001-UP
2шт.
30
KB21011-30630
SPRING
SN: 15001-UP
1шт.
31
KB21011-32801
WIPER
SN: 15001-UP
1шт.
32
KB21011-31707
PLATE
SN: 15001-UP
1шт.
33
KB21011-30565
PIN
SN: 15001-UP
1шт.
34
KB93317-05322
NUT
SN: 15001-UP
1шт.
35
KB21011-33453
PLATE
SN: 15001-UP
1шт.
36
KB21001-01456
BOLT,HEAD
SN: 15001-UP
1шт.
37
KB95111-02550
O-RING
SN: 15001-UP
1шт.
38
KB21001-01458
SHIM
SN: 15001-UP
-2шт.
39
KB25113-30127
TUBE,COIL
SN: 15001-UP
1шт.
40
KB95111-02550
O-RING
SN: 15001-UP
1шт.
41
KB21011-31095
CAP
SN: 15001-UP
1шт.
42
KB21001-01457
BOLT,HEAD
SN: 15001-UP
2шт.
43
42A-64-13270
PLUG
SN: 15001-UP
1шт.
44
42A-64-13280
O-RING
SN: 15001-UP
1шт.
45
42A-64-13220
RELIEF VALVE ASS'Y,MAIN
SN: 15001-UP
1шт.
47
42A-64-13230
RELIEF VALVE ASS'Y,OVERLOAD
SN: 15001-UP
4шт.
49
42A-64-13250
PLUG,(FOR SHIPPING)
SN: 15001-UP
6шт.
Выбрано товаров: 55
