Запчасти Komatsu WA30-5-CN 3-Х СЕКЦИОНН. CNTROL КЛАПАН (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

363-876-3131

VALVE ASS'Y

SN: 26001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1682-01A0 AND Y1682-02A0.

-1шт.

|$$3

THE KAYABA KOGYO PART NUMBER IS THAT KB IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

363-43-38470

PLATE

SN: 26001-UP

2шт.

|2

42A-64-13160

INLET SECTION ASS'Y

SN: 26001-UP

1шт.

2

KB21011-30336

HOUSING,INLET

SN: 26001-UP

1шт.

3

KB21001-00106

O-RING

SN: 26001-UP

1шт.

|4

363-876-3120

SPOOL SECTION ASS'Y

SN: 26001-UP

1шт.

4

0

HOUSING

SN: 26001-UP

1шт.

5

KB21011-32404

POPPET

SN: 26001-UP

1шт.

6

KB21011-30604

SPRING

SN: 26001-UP

1шт.

7

KB21001-00106

O-RING

SN: 26001-UP

1шт.

8

0

SPOOL

SN: 26001-UP

1шт.

9

KB21001-00689

O-RING

SN: 26001-UP

2шт.

10

KB21011-32801

WIPER

SN: 26001-UP

2шт.

11

KB21011-31702

PLATE

SN: 26001-UP

2шт.

12

KB91111-60102

SCREW

SN: 26001-UP

2шт.

13

KB21011-30702

SEAT,SPRING

SN: 26001-UP

2шт.

14

KB21011-30612

SPRING

SN: 26001-UP

1шт.

15

KB21011-30507

SCREW,CAP

SN: 26001-UP

1шт.

16

KB21011-31011

CAP

SN: 26001-UP

1шт.

17

KB92703-06181

BOLT,HEAD

SN: 26001-UP

2шт.

|18

363-64-33220

SPOOL SECTION ASS'Y

SN: 26001-UP

1шт.

18

0

HOUSING

SN: 26001-UP

1шт.

19

KB21011-32404

POPPET

SN: 26001-UP

1шт.

20

KB21011-30604

SPRING

SN: 26001-UP

1шт.

21

KB21001-00106

O-RING

SN: 26001-UP

1шт.

22

0

SPOOL

SN: 26001-UP

1шт.

23

KB21001-00689

O-RING

SN: 26001-UP

1шт.

24

KB21011-32801

WIPER

SN: 26001-UP

1шт.

25

KB21011-31702

PLATE

SN: 26001-UP

1шт.

26

KB91111-60102

SCREW

SN: 26001-UP

2шт.

27

KB21011-31856

SLEEVE

SN: 26001-UP

1шт.

28

KB21001-00689

O-RING

SN: 26001-UP

1шт.

29

KB95151-02800

O-RING

SN: 26001-UP

1шт.

30

KB21011-30702

SEAT,SPRING

SN: 26001-UP

2шт.

31

KB21011-30630

SPRING

SN: 26001-UP

1шт.

32

KB21011-32801

WIPER

SN: 26001-UP

1шт.

33

KB21011-31707

PLATE

SN: 26001-UP

1шт.

34

KB21011-30565

PIN

SN: 26001-UP

1шт.

35

KB93317-05322

NUT

SN: 26001-UP

1шт.

36

KB21011-33453

PLATE

SN: 26001-UP

1шт.

37

KB21001-01456

BOLT,HEAD

SN: 26001-UP

1шт.

38

KB95111-02550

O-RING

SN: 26001-UP

1шт.

39

KB21001-01458

SHIM

SN: 26001-UP

-2шт.

40

KB25113-30127

TUBE,COIL

SN: 26001-UP

1шт.

41

KB95111-02550

O-RING

SN: 26001-UP

1шт.

42

KB21011-31095

CAP

SN: 26001-UP

1шт.

43

KB21001-01457

BOLT,HEAD

SN: 26001-UP

2шт.

44

42A-64-13270

PLUG

SN: 26001-UP

1шт.

45

42A-64-13280

O-RING

SN: 26001-UP

1шт.

46

42A-64-13220

RELIEF VALVE ASS'Y,MAIN

SN: 26001-UP

1шт.

47

KB21001-00036

O-RING

SN: 26001-UP

1шт.

48

42A-64-13230

RELIEF VALVE ASS'Y,OVERLOAD

SN: 26001-UP

4шт.

49

KB21001-00036

O-RING

SN: 26001-UP

1шт.

50

42A-64-13250

PLUG,(FOR SHIPPING)

SN: 26001-UP

6шт.
