Запчасти Komatsu WA30-5-CB КАБИНА (/) (БОКОВ. ОКНА) (С PATO LIGHT И ЗАДН. LIGHT) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

362-56-46020

CAB ASS'Y,(WITH PATO LIGHT)

SN: 26001-UP

1шт.

|1

362-56-46030

CAB ASS'Y,(WITH REAR LIGHT)

SN: 26001-UP

1шт.

|1

362-56-46040

CAB ASS'Y,(WITH PATO AND REAR LIGHT)

SN: 26001-UP

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A1 TO K0210-10A1.

-1шт.

1

362-56-41411

GLASS

SN: 26001-UP

1шт.

2

362-56-42330

SEAL

SN: 26001-UP

1шт.

3

363-56-31150

WASHER

SN: 26001-UP

4шт.

4

363-56-31110

SASH ASS'Y

SN: 26001-UP

1шт.

5

363-56-31210

FRAME

SN: 26001-UP

1шт.

6

363-56-31220

STRIP

SN: 26001-UP

1шт.

7

363-56-31230

STRIP

SN: 26001-UP

1шт.

8

363-56-31240

STRIP

SN: 26001-UP

1шт.

9

363-56-31250

RUBBER

SN: 26001-UP

1шт.

10

363-56-31260

SEAL

SN: 26001-UP

1шт.

11

363-56-31120

GLASS

SN: 26001-UP

1шт.

12

363-56-31130

GLASS

SN: 26001-UP

1шт.

13

421-56-11960

CATCH

SN: 26001-UP

2шт.

14

421-56-11970

CATCH

SN: 26001-UP

6шт.

15

425-54-16250

LOCK ASS'Y,L.H.

SN: 26001-UP

1шт.

16

425-54-16270

SCREW

SN: 26001-UP

1шт.

17

425-54-16280

SCREW

SN: 26001-UP

2шт.

18

425-54-16260

LOCK ASS'Y,R.H.

SN: 26001-UP

1шт.

19

425-54-16270

SCREW

SN: 26001-UP

1шт.

20

425-54-16280

SCREW

SN: 26001-UP

2шт.

21

425-54-16570

SCREW

SN: 26001-UP

2шт.

22

01580-10403

NUT

SN: 26001-UP

16шт.

23

01224-70412

SCREW

SN: 26001-UP

16шт.

24

01224-70516

SCREW

SN: 26001-UP

7шт.

25

01642-20508

WASHER

SN: 26001-UP

7шт.

26

01580-10504

NUT

SN: 26001-UP

7шт.
