Запчасти Komatsu WA270PT-3 active ЦИЛИНДР КОВША ГИДРАВЛИКА

1

707-00-02430

BUCKET CYLINDER

EnglischBem: LEFT

1шт.

2

707-00-02440

BUCKET CYLINDER

EnglischBem: RIGHT

1шт.

3

721-11-11810

CYLINDER

DeutschDesc: ZYLINDER

1шт.

4

721-11-11820

CYLINDER

DeutschDesc: ZYLINDER

1шт.

5

707-76-60110

BUSHING

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

1шт.

6

707-29-11380

GUIDE BUSH

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

1шт.

7

07177-06030

PILOT

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

1шт.

8

707-51-60030

SEAL

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

1шт.

9

141-63-93270

STRIPPER

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

1шт.

10

07179-12074

SNAP RING

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

1шт.

11

07000-02110

O-RING

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

1шт.

12

07146-02106

BACK-UP RING

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

1шт.

13

07000-12105

O-RING

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (2) Kit

1шт.

14

707-59-60110

CYLINDER ROD

DeutschDesc: KOLBENSTANGE

1шт.

15

707-59-60090

CYLINDER ROD

DeutschDesc: KOLBENSTANGE

1шт.

16

707-36-11040

PISTON

EnglischBem: NOTE: Pos. (16) included in Pos. (1) and (2) Kit

1шт.

17

707-44-11180

SEAL

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (2) Kit

1шт.

18

07156-01112

PILOT

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (2) Kit

1шт.

19

07165-13941

NUT

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (2) Kit

1шт.

20

707-99-35580

GASKET KIT

DeutschDesc: DICHTUNGSSATZ

1шт.
