Запчасти Komatsu WA270-3 active ГИДРОЦИЛИНДР ПОДЪЕМА ГИДРАВЛИКА

1

42Y-63-H2100

LIFT CYLINDER

DeutschDesc: HUBZYLINDER

1шт.

2

42Y-63-H2200

LIFT CYLINDER

DeutschDesc: HUBZYLINDER

1шт.

3

42Y-63-H0P36

BARREL

DeutschDesc: ZYLINDERROHR

1шт.

4

42Y-63-H0P37

BARREL

DeutschDesc: ZYLINDERROHR

1шт.

5

42Y-63-H0P38

BUSHING

EnglischBem: NOTE: Pos. (5) included in Pos. (3) and (4) Kit

1шт.

6

42Y-63-H0P39

CYLINDER ROD

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

1шт.

7

42Y-63-H0P40

GUIDE BUSH

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

1шт.

8

42Y-63-H0P41

STRIPPER

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (8) included in Pos. (1) and

1шт.

9

42Y-63-H0P42

SEAL

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (9) included in Pos. (1) and

1шт.

10

42Y-63-H0P43

PILOT

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (10) included in Pos. (1) and

1шт.

11

42Y-63-H0P44

TAB WASHER

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (11) included in Pos. (1) and

1шт.

12

42Y-63-H0P45

O-RING

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (12) included in Pos. (1) and

1шт.

13

418-63-K1240

RING

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (13) included in Pos. (1) and

1шт.

14

418-63-K1230

O-RING

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (14) included in Pos. (1) and

1шт.

15

42Y-63-H0P46

PISTON

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (2) Kit

1шт.

16

42Y-63-H0P47

PILOT

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (16) included in Pos. (1) and

1шт.

17

418-63-K1250

PISTON RING

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (17) included in Pos. (1) and

1шт.

18

42Y-63-H0P13

GRUB SCREW

EnglischBem: BELONGS TO THE SEAL KIT NOTE: Pos. (18) included in Pos. (1) and

1шт.

19

42Y-63-H0P48

UNION

EnglischBem: NOTE: Pos. (19) included in Pos. (3) and (4) Kit

1шт.

20

42Y-63-H0P49

GASKET KIT

DeutschDesc: DICHTUNGSSATZ

1шт.
