Запчасти Komatsu WA250PZ-6 КОВШ (.CBM) (С TEETH) (ТИП C) T РАБОЧЕЕ ОБОРУДОВАНИЕ

1

418-71-H2110

BUCKET ASSEMBLY

SN: H00051-UP

1шт.

2

42Y-70-H2C90

EDGE, (WELDED)

SN: H00051-UP

1шт.

3

421-70-H2431

PLATE, (LIMITED SUPPLY)

SN: H00051-UP

1шт.

4

418-71-H2C50

WEAR PLATE

SN: H00051-UP

2шт.

5

418-71-H2C50

WEAR PLATE, (WELDED)

SN: H00051-UP

2шт.

6

418-71-H2590

TRAY REINFORCEMENT, (WELDED)

SN: H00051-UP

1шт.

7

418-71-H2600

SKID, (WELDED)

SN: H00051-UP

2шт.

8

418-71-H2780

EDGE, (WELDED)

SN: H00051-UP

1шт.

9

418-71-H2380

SIDE WALL, (WELDED)

SN: H00051-UP

1шт.

10

418-71-H2780

EDGE, (WELDED)

SN: H00051-UP

1шт.

11

418-71-H2390

SIDE WALL, (WELDED)

SN: H00051-UP

1шт.

12

416-71-H2580

BOLT

SN: H00051-UP

4шт.

13

01643-32260

WASHER

SN: H00051-UP

4шт.

14

421-70-H2A20

NUT

SN: H00051-UP

4шт.

15

04418-03080

PIN

SN: H00051-UP

4шт.

16

419-71-H2920

TOOTH HOLDER, (WELDED)

SN: H00051-UP

1шт.

17

419-71-H2290

TOOTH HOLDER, (WELDED)

SN: H00051-UP

6шт.

18

419-71-H2910

TOOTH HOLDER, (WELDED)

SN: H00051-UP

1шт.

19

419-71-H2310

TOOTH

SN: H00051-UP

8шт.

20

419-71-H2320

SAFETY CATCH

SN: H00051-UP

8шт.
