Запчасти Komatsu WA250PZ-6 МАРКИРОВКА, EXTERIOR (№789-) МАРКИРОВКА

1

09161-23000

Plate, Warning, Articulation Lock

SN: 75896-UP

1шт.

2

09653-03001

Plate, Warning, High Temperature

SN: 75896-UP

1шт.

3

418-U77-4710

Decal, Machine Model,L.H.

SN: 75896-UP

1шт.

4

418-U77-4720

Decal, Machine Model,R.H.

SN: 75896-UP

1шт.

5

418-93-42130

Plate, Stripe

SN: 75896-UP

2шт.

6

418-93-41720

Oil Chart

SN: 75896-UP

1шт.

7

09960-01601

Mark, Lift Point and Tie Down Point Marks

SN: 75896-UP

4шт.

8

09668-03001

Plate, Warning, Hot Water

SN: 75896-UP

1шт.

8

418-93-22240

Decal

SN: 75896-UP

1шт.

9

Decal, Remote Grease, Rear Axle

SN: 75896-UP

1шт.

10

Decal, Radiator Drain

SN: 75896-UP

1шт.

11

Plate, Remote Grease, Cylinder

SN: 75896-UP

1шт.

12

09669-0000E

Plate, Symbol, Fuel Filler,Inlet

SN: 75896-UP

1шт.

13

418-93-42410

Plate, Stripe, Low Clearance

SN: 75896-UP

4шт.

14

418-93-43341

Plate, Caution Cleaning Core, Rotation Caution

SN: 75896-UP

1шт.

15

09690-C0800

Plate, Komatsu Logo

SN: 75896-UP

2шт.

16

20Y-00-41530

Plate, Symbol, Ecot3

SN: 75896-UP

1шт.

17

418-93-42240

Plate, Prefilter Cation, Pre Filter

SN: 75896-UP

1шт.

18

09162-23000

Plate, Danger, Keep Off

SN: 75896-UP

2шт.

19

09807-C0883

Plate, Danger, Keep Out under Work Equipment

SN: 75896-UP

2шт.

20

09667-03001

Plate, Caution, Rotating Object

SN: 75896-UP

2шт.

21

09812-13000

Plate, Danger, Keep a Safe Distance

SN: 75896-UP

2шт.

22

09808-03000

Plate, Warning, Battery Cables

SN: 75896-UP

2шт.

23

09963-03001

Tag, Danger, Do Not Operate

SN: 75896-UP

1шт.

24

14X-98-35181

Plate, Reflector, Reflector

SN: 75896-UP

2шт.

25

09659-53000

Plate, Warning, Explosion Hazard

SN: 75896-UP

4шт.

26

21T-00-32830

Plate, Emergency Stop Switch

SN: 75896-UP

2шт.
