Запчасти Komatsu WA250PZ-6 МАРКИРОВКА, EXTERIOR (№77-) МАРКИРОВКА, ИСПАНИЯ, TEXT ТИП

1

09161-21000

Plate, Warning, Articulation Lock

SN: 75750-UP

1шт.

2

09653-01001

Plate, Warning, High Temperature

SN: 75750-UP

2шт.

3

418-U77-4710

Decal, Machine Model

SN: 75750-UP

1шт.

4

418-U77-4720

Decal, Machine Model

SN: 75750-UP

1шт.

5

418-93-42130

Plate, Stripe

SN: 75750-UP

2шт.

6

418-93-41720

Oil Chart

SN: 75750-UP

1шт.

7

09960-01601

Mark, Lift Point and Tie Down Point Marks

SN: 75750-UP

4шт.

7

418-V00-3110

Plate

SN: 75750-UP

1шт.

8

Plate, Remote Grease (Rear Axel)

SN: 75750-UP

1шт.

9

Plate, Radiator Drain

SN: 75750-UP

1шт.

10

Plate, Remote Grease (Bucket Cylinder)

SN: 75750-UP

1шт.

11

09669-0000E

Plate, Symbol, Fuel Filler

SN: 75750-UP

1шт.

12

418-93-42410

Plate, Stripe

SN: 75750-UP

4шт.

13

417-V00-4130

Plate

SN: 75750-UP

1шт.

14

09690-C0800

Plate, Komatsu Logo

SN: 75750-UP

2шт.

15

20Y-00-41530

Plate, Symbol, Ecot3

SN: 75750-UP

1шт.

16

418-93-42250

Plate, Prefilter Caution

SN: 75750-UP

1шт.

17

09162-21000

Plate, Danger, Keep Off

SN: 75750-UP

2шт.

18

09807-C0883

Plate, Danger, Keep Out under Work Equipment

SN: 75750-UP

2шт.

19

09667-01001

Plate, Caution, Rotating Object

SN: 75750-UP

2шт.

20

09808-01000

Plate, Warning, Battery Cables

SN: 75750-UP

2шт.

21

09812-11000

Plate, Danger, Keep a Safe Distance

SN: 75750-UP

2шт.

22

09963-01001

Tag, Danger, Do Not Operate

SN: 75750-UP

1шт.

23

09668-01001

Plate, Warning, Hot Water

SN: 75750-UP

1шт.

24

09659-51000

Plate, Warning, Explosion Hazard

SN: 75750-UP

4шт.

25

14X-98-35181

Plate, Reflector

SN: 75750-UP

2шт.
