Запчасти Komatsu WA250PZ-6 МАРКИРОВКА (АНГЛ.) (PICTORIAL)(№7-) МАРКИРОВКА

1

09161-C0641

PLATE, SAFETY,FRAME LOCK

SN: 75001-UP

1шт.

2

09653-A0641

PLATE, SAFETY,HOT OIL HAZARD, HYD. TANK CAP

SN: 75001-UP

2шт.

3

418-U77-4710

PLATE,L.H.

SN: 75001-UP

1шт.

4

418-U77-4720

PLATE,R.H.

SN: 75001-UP

1шт.

5

418-93-42130

PLATE,STRIPE

SN: 75001-UP

2шт.

6

418-93-42351

OIL CHART

SN: 75001-UP

1шт.

7

09960-01601

PLATE, MARK,LIFT AND TIE DOWN POINT MARK

SN: 75001-UP

4шт.

|$10

418-93-22240

PLATE

SN: 75001-UP

1шт.

8

0

PLATE,REMOTE GREASE, REAR AXLE

SN: 75001-UP

1шт.

9

0

PLATE,RADIATOR DRAIN

SN: 75001-UP

1шт.

10

0

PLATE,REMOTE GREASE, CYLINDER

SN: 75001-UP

1шт.

11

09669-0000E

PLATE, CAUTION,DIESEL FUEL INLET

SN: 75001-UP

1шт.

12

418-93-42410

PLATE,LOW CLARRANCE

SN: 75001-UP

4шт.

13

418-93-43341

PLATE

SN: 75001-UP

1шт.

14

09690-C0800

PLATE, MARK,KOMATSU

SN: 75001-UP

2шт.

15

20Y-00-41530

PLATE, MARK,ECOT 3

SN: 75001-UP

1шт.

16

418-93-42240

PLATE,PRE FILTER CAUTION

SN: 75001-UP

1шт.

17

09162-C0641

PLATE, SAFETY,ARTICULATE

SN: 75001-UP

2шт.

18

09807-C0883

PLATE, SAFETY,KEEP OUT, WORK EQUIPMENT FALL

SN: 75001-UP

2шт.

19

09667-A0880

PLATE, SAFETY,KEEP AWAY FAN AND FAN-BELT

SN: 75001-UP

2шт.

20

09806-C0883

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 75001-UP

2шт.

21

09808-A1201

PLATE, SAFETY,ELECTRIC SHOCK FROM CABLE

SN: 75001-UP

2шт.

22

09963-A1640

TAG

SN: 75001-UP

1шт.

23

14X-98-35181

PLATE,REFLECTOR

SN: 75001-UP

2шт.

24

09659-A057B

PLATE, SAFETY,EXPLOSION HAZARD

SN: 75491-UP

4шт.
