Запчасти Komatsu WA250PZ-5 НАСОС (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

418-18-31101

PUMP

SN: H50051-UP

1шт.

|$2

THE UCHIDA YUATSU PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

ROTARY GROUP

SN: H50051-UP

1шт.

2

HD CONTROL

SN: H50051-UP

1шт.

3

COVER

SN: H50051-UP

1шт.

4

GEAR PUMP ASSEMBLY

SN: H50051-UP

1шт.

5

VALVE

SN: H50051-UP

1шт.

6

DA CARTRIDGE ASSEMBLY

SN: H50051-UP

1шт.

7

UC1100679859

HOUSING B1

SN: H50051-UP

1шт.

8

UC1704181927

ORIFICE

SN: H50051-UP

1шт.

9

UC1704497149

PIN

SN: H50051-UP

2шт.

10

UC4100104453

PLUG

SN: H50051-UP

1шт.

|$13

0

PLUG

SN: H50051-UP

1шт.

|$14

UC1301205004

O-RING

SN: H50051-UP

1шт.

11

UC4100104426

PLUG

SN: H50051-UP

4шт.

|$16

0

PLUG

SN: H50051-UP

1шт.

|$17

UC1301169009

O-RING

SN: H50051-UP

1шт.

12

UC1701544279

PIN B1

SN: H50051-UP

2шт.

13

UC1701533646

PLUG

SN: H50051-UP

4шт.

14

UC1700879134

PLUG

SN: H50051-UP

1шт.

15

PIN

SN: H50051-UP

1шт.

16

NUT

SN: H50051-UP

1шт.

17

UC1704267076

ORIFICE

SN: H50051-UP

1шт.

18

UC1181066129

ORIFICE

SN: H50051-UP

1шт.

19

UC4100695445

BUSHING ASSEMBLY

SN: H50051-UP

1шт.

|$26

0

BUSHING

SN: H50051-UP

1шт.

|$27

UC1301181009

O-RING

SN: H50051-UP

1шт.

20

UC1100695026

BRACKET

SN: H50051-UP

1шт.

21

UC1301582008

BOLT

SN: H50051-UP

1шт.

22

0

PLATE ASSEMBLY

SN: H50051-UP

1шт.
