Запчасти Komatsu WA250PT-3MC FIG. U-A МАРКИРОВКА - ФРАНЦИЯ МАРКИРОВКА

|$0

417-933-A170

PLATE KIT

SN: A78001 --UP

1шт.

1

NSS

PLATE, SAFETY - KEEP OUT

SN: A78001 --UP

2шт.

2

NSS

PLATE, SAFETY - SAFETY BAR

SN: A78001 --UP

1шт.

3

NSS

PLATE, INSTRUCTION - FUEL

SN: A78001 --UP

1шт.

4

NSS

PLATE, SAFETY - RADIATOR CAP

SN: A78001 --UP

1шт.

5

NSS

PLATE, INSTRUCTION - ENGINE OIL

SN: A78001 --UP

1шт.

6

NSS

PLATE, CAUTION - BRAKE OIL

SN: A78001 --UP

1шт.

7

NSS

PLATE, SAFETY - HYDRAULIC TANK CAP

SN: A78001 --UP

1шт.

8

NSS

PLATE, CAUTION - BATTERY CABLE

SN: A78001 --UP

1шт.

9

417-93-21141

PLATE, MARK - KOMATSU

SN: A78001 --UP

1шт.

10

417-93-21150

PLATE, STRIPE - L.H.

SN: A78001 --UP

1шт.

11

417-93-21160

PLATE, STRIPE - R.H.

SN: A78001 --UP

1шт.

12

418-93-21220

PLATE, MARK - WA250

SN: A78001 --UP

2шт.

13

418-U77-A160

CHART, OIL

SN: A78001 --UP

1шт.

14

09960-01001

PLATE, MARK HANDLING - LIFT HERE

SN: A78001 --UP

4шт.

15

417-T80-A770

DECAL, TOOL CARRIER

SN: A78001 --UP

2шт.

16

417-933-A160

PLATE, WARNING COUPLER

SN: A78001 --UP

2шт.

17

418-93-A2320

PLATE, MARK, AVANCE - FRONT HOOD

SN: A78001 --UP

2шт.

18

418-93-A2340

DECAL, PLUS - HOOD

SN: A78001 --UP

2шт.

19

09807-C0880

PLATE, SAFE LIFT ARM

SN: A78001 --UP

2шт.

20

09812-15000

PLATE, SAFE DISTANCE

SN: A78001 --UP

2шт.

21

419-93-A2310

DECAL, WINDOW - REAR

SN: A78001 --UP

1шт.

22

418-93-A2330

DECAL, WINDOW - FRONT

SN: A78001 --UP

1шт.

23

09667-05001

PLATE, SAFETY - FAN

SN: A78001 --UP

2шт.

24

09690-C0450

DECAL, KOMATSU

SN: A78001 --UP

2шт.

25

419-933-A150

DECAL, BATTERY BOOST

SN: A78001 --UP

1шт.

N/I

418-933-A250

DECAL, DOWNHILL BRAKING

SN: A78001 --UP

1шт.

N/I

417-933-A160

DECAL, COUPLER WARNINGS

SN: A78001 --UP

1шт.
